Ovation F-915VW is a high-power, variable white Fresnel-style fixture that utilizes our unique 6-color LED system. This fixture projects a bright, beautifully soft field of light in nearly any temperature of white with high CRI and CQS making it ideal for theatres and TV studios. Each Color Temperature can be further adjusted for +/- green and a motorized zoom with a 17° – 85° field range allows you to add light where it is needed. The Color Temperature and hue along with zoom and output can be controlled via DMX or on-board dials.
• Variable white LED Fresnel lighting fixture for theatre, film and production
• Soft and even field of light
• Smooth, motorized zoom from 17° to 85° beam range
• Color Temperature Presets from 2800 K to 8000 K with high CRI and CQS
• Beautiful 16-bit dimming
• Proprietary LED engine delivers tremendous, equal output at all color temperatures
• Easy to use on board control of color temperature, zoom and dimming
• +/- Green adjustment via DMX or on-board control
• Independent color control over the 6-color engine when a splash of color is needed
• RDM (Remote Device Management) for added flexibility
• Adjustable PWM (Pulse Width Modulation) to avoid flickering on camera
• Virtually silent operation for use in studio and theatre applications
• OPTICAL:
• Light Source: 89 LEDs (6 red, 15 orange-red, 8 green, 12 blue, 16 royal blue, 32 lime) 3 W, (960 mA), 50,000 hours life expectancy
• Color Temperature (Range): 2800 to 8000 K
• CRI: 88-92
• Beam Angle: 17° to 54°
• Field Angle: 30° to 85°
• Zoom Range: 17° to 85°
• Lumens (30°): 4,143
• Lumens (85°): 6,792
• Illuminance (30°): 1,748 lux @ 5 m
• Illuminance (85°): 414 lux @ 5 m
• Selectable PWM: 600 Hz, 1200 Hz, 2000 Hz, 4000 Hz, 6000 Hz, 25,000 Hz
• DYNAMIC EFFECTS:
• Dimmer: Electronic
• Zoom: Motorized
• Strobe Rate: 0 to 27 Hz
• Standalone Color Mixing: Yes
• Color Temperature Presets: Yes
• Dim Modes: 4
• Built-in Automated Programs: No
• CONSTRUCTION / PHYSICAL:
• Dimensions: 22.41 x 12.59 x 10.82in (569.44 x 320 x 275 mm)
• Weight: 18.6 lb (8.5 kg)
• Exterior Color: Black
• Housing Material: Aluminum alloy, Aluminum die-cast
• CONNECTIONS:
• Power Connection: Edison (local) plug to Seetronic Powerkon IP65
• Power Input: Seetronic Powerkon IP65
• Power Output: Seetronic Powerkon IP65
• Data Connectors: 3- and 5-pin XLR
• Cable Length (Power): 5 ft (1.5 m)
• CONTROL:
• Control Protocol: DMX, RDM
• DMX Channels: 1, 4, 6, 7, 9, 13, 16 or 18
• Modes/Personalities: 8 personalities (1, 4, 6, 7, 9, 13, 16, 18)
• ELECTRICAL:
• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power Linking: 5 units @ 120 V; 8 units @ 208 V; 9 units @ 230 V
• Power and Current: 271 W, 2.3 A @ 120 V, 60 Hz
• Power and Current: 262 W, 1.433 A @ 208 V, 60 Hz
• Power and Current: 258 W, 1.209 A @ 230 V, 50 Hz
• Certifications / Qualifications: CE, MET, FCC, UKCA
• IP Rating: IP20, dry location
• Temperature (startup): -4 °F to 113 °F (-20 °C to 45 °C)
• Temperature (operating): -22 °F to 113 °F (-30 °C to 45 °C
• (1) Chauvet Professional Ovation F-915VW
• (1) Seetronic Powerkon IP65 power cord
• (1) Gel frame (7.5 in/191 mm accessories)
