Our newest STRIKE design introduces dynamic dual-layer pixel effects with a punchy flair that brings totally new and unique looks to our tour-proven STRIKE family of IP65-rated strobes and blinders. STRIKE V features dual LED diodes, under a variable electronic frost plate that can change beam angles instantly at the press of a button, and together offer fresh new multicolor creative possibilities. Advanced eye-candy effects, vibrant color washes, and stunning strobe capabilities from a motorized 180° tilting strobe/wash hybrid designed for powerful performance in the most demanding applications and conditions.
• Fully featured, high-power, 180° tilting hybrid strobe/wash with IP65 rating for all-weather use
• 48 individually controllable pixels across two layers of LEDs
• Variable electronic frost for added eye candy effects
• Included magnetically attachable stealth filter for hiding the LEDs when not in use
• Multiple mounting locations and repositionable yoke with ¼ turn adaptors for creative and convenient rigging options in vertical and horizontal orientations
• RDM control over DMX for fixture reporting
• 16-bit dimming of master dimmer for smooth control of fades
• Easy-to-use OLED display
• Rugged design for years of rough use in the most extreme conditions.
• Adjustable Pulse Width Modulation (PWM) for added flexibility
• USB port for fixture software updates
• Built-in alignment pins to insure perfectly straight linear arrays
• Failsafe Ethernet connectivity allows for data to pass even if fixture power is lost
• OPTICAL:
• Light Source: 24 LEDs top plate (quad-color RGBW), 6W, 50,000 hours life expectancy
• Light Source: 24 LEDs bottom plate (quad-color RGBW), 50W, 50,000 hours life expectancy
• Beam Angle (Combine): 9.9°
• CRIBeam Angle (Dot): 105.7°
• Beam Angle (Cell): 9.9°
• Beam Angle (w/E-Frost Combine): 50.3°
• Beam Angle (w/E-Frost Dot): 103.1°
• Beam Angle (w/E-Frost Cell): 46.8°
• Field Angle (Combine): 17.6°
• Field Angle (Top Plate): 153.1°
• Field Angle (Cell): 17.5°
• Field Angle (w/E-Frost Combine): 125°
• Field Angle (w/E-Frost Dot): 155.6°
• Field Angle (w/E-Frost Cell): 117.2°
• Lumens (Combine): 19,589
• Lumens (Dot): 1,912
• Lumens (Cell): 17,127
• Lumens (w/E-Frost Combine): 13,406
• Lumens (w/E-Frost Dot): 1,633
• Lumens (w/E-Frost Cell): 15,769
• Illuminance (Combine): 16,779 lux @ 5 m
• Illuminance (Dot): 29 lux @ 5 m
• Illuminance (Cell): 16,789 lux @ 5 m
• Illuminance (w/E-Frost Combine): 539 lux @ 5 m
• Illuminance (w/E-Frost Dot): 26 lux @ 5 m
• Illuminance (w/E...: 5 ft (1.5 m)
• CONTROL:
• Control Protocol: Art-Net, DMX, RDM, sACN
• DMX, ArtNet, and sACN Channels single mode: 29,222,314
• DMX, ArtNet, and sACN Channels Dual Mode Pixels: 144,192,240,288
• ArtNet and sACN Channels Multi-Layer Control Movem: 30
• ArtNet and sACN Channels Multi-Layer Control Dot P: 72,96,120,144
• ArtNet and sACN Channels Multi-Layer Control Cell: 72,96,120,144
• ELECTRICAL:
• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current: 747 W, 7.54 A @ 100 V, 60 Hz
• Power and Current: 747 W, 6.20 A @ 120 V, 60
• Power and Current: 719 W, 3.63 A @ 208 V, 60 Hz
• Power and Current: 717 W, 3.28 A @ 230 V, 50 Hz
• Power and Current: 717 W, 3.17 A @ 240 V, 50 Hz
• BATTERY:
• Battery Type: Lithium Ion
• Rechargeable: Yes
• CERTIFICATION/QUALIFICATIONS:
• Certifications / Qualifications: CE, MET, ROHS, FCC
• IP Rating: IP65, temporary outdoor/wet use, with pressure equalizing M12 GORE valve
• Temperature (Ambient): 14 °F to 113 °F (-10 °C to 45 °C)
• (1) Chauvet Professional STRIKE V
• (1) Seetronic Powerkon IP65 Power Cable
• (1) Omega Bracket
• (1) Stealth Filter
