DESCRIPTION

AcousticCoverage™ is designed to offer sound system designers and installers a cost effective solution for applications where voice reinforced coverage is of primary concern, while providing improved musicality often not seen in typical BGM class products. Applications for AcousticCoverage™ speakers include wide area paging systems and background music and more.

FEATURES
    AC-C2T
    • High Quality 2.75" fulll-range transducer provides a natural rise in high frequency extension
    • Ported baffle for increased low frequency extension down to 70Hz
    • Low saturation 70/100V transformers with 8 ohm bypass
    • 4 pole Euroblock connector eases system writing
    • Advanced voicing filter sets using QSC Intrinsic Correction™ available through either Q-SYS™ processing or CXD amplifier platforms
    • White (RAL 9010) with UV inhibitors to match complimenting QSC product families
    • Complete EASE, CAD, and BIM information available online

    AC-C4T
    • High quality 4” full-range transducer provides exceptional clarity through the critical voice range.
    • Ported baffle for increased low frequency extension down to 70 Hz
    • Low saturation 70/100V transformers with 8 ohm bypass.
    • Advanced voicing filter sets using QSC Intrinsic Correction™ available through either Q-SYS™ processing or CXD amplifier platforms.
    • White (RAL 9010) with UV inhibitors to match complimenting QSC product families.
    • 4 pole Euroblock connector eases system wiring
    • Complete EASE, CAD & BIM information available online

    AC-C6T
    • High quality 6.5-inch 2-way system provides exceptional clarity through the critical voice range.
    • Low-saturation 70V/100V transformers with 8-ohm bypass.
    • 4-pole Euroblock connector for easy system wiring.
    • Advanced voicing filter sets using QSC Intrinsic Correction™ are available through either Q-SYS processing or CXD amplifier platforms.
    • White (RAL 9010) with UV inhibitors to match complementing QSC product families.
    • Complete EASE, CAD, and BIM information available online.

    AC-C8T
    • High quality transducers provide exceptional clarity through the critical voice range.
    • Improved musicality often not seen in typical BGM class products.
    • Ported baffle for increased low frequency extension down to 52 Hz.
    • Low saturation 70/100V transformers with 8 ohm bypass.
    • 4-pole Euroblock connector eases system wiring.
    • Advanced voicing via QSC Intrinsic Correction™, applied using the Q-SYS™ Platform or CXD Series amplifier platforms.
    • White (RAL 9010) with UV inhibitors to match complimenting QSC product families.
SPECIFICATIONS
    AC-C2T
    • Effective Frequency Range: 70Hz - 20 kHz
    • Rated Noise Power / Voltage: 16 watts / 11.3 volts (rms)
    • Broad Band Sensitivity: 84 dB
    • Coverage Angle (-6 dB): 170°
    • Directivity Factor: 2.5
    • Directivity Index: 4 dB
    • Maximum Continuous SPL: 96 dB
    • Maximum Peak SPL: 102 dB
    • Rated Impedance: 8 ohms
    • Transducer: 2.75 in (70mm) weather treated paper cone
    • Input Connector Type: Euroblock connectors with parallel output terminals
    • Baffle Material: Painted ABS Polymer
    • Grille Material: Powder coated steel
    • Back Can Material: Powder Coated Steel
    • Testing: Listed UL1480, UL2043 safe for use in ai handling space

    AC-C4T
    • Effective frequency range: 70 Hz to 16 kHz
    • Rated noise power / voltage: 16 watts / 11.3 volts (rms)
    • Broad-band sensitivity: 89 dB
    • Coverage angle (-6 dB): 140° (500 Hz to 5 kHz)
    • Maximum continuous SPL: 101 dB
    • Maximum peak SPL: 107 dB
    • Rated impedance: 8 ohms
    • Transformer taps: 70v - 16, 8, 4, 2, 1 watts and 8-ohm bypass.
    • Transformer taps: 100V - 16, 8, 4, 2, watts and 8-ohm bypass
    • Transducer: 4.5-inch Polypropylene cone with butyl rubber surround
    • Input connector type: Euroblock connector with parallel output terminals

    AC-C6T
    • Effective frequency range: 65 Hz to 20 kHz
    • Rated noise power / voltage: 30 watts / 15.5 volts (rms)
    • Broad-band sensitivity: 89 dB SPL
    • Coverage angle (-6 dB): 110° (500 Hz to 5 kHz)
    • Maximum continuous SPL: 104 dB
    • Maximum Peak SPL: 110 dB
    • Rated impedance: 70 V - 30, 15, 7.5, 3.7, 1.9 watts and 8-ohm bypass
    • Transformer taps: 100 V - 30, 15, 7.5, 3.8, watts and 8-ohm bypass
    • HF Transducer: .86-inch silk dome tweeter, coaxially mounted
    • LF Transducer: 6.5-inch Polypropylene cone with butyl rubber surround
    • Input connector type: Euroblock connector with parallel output terminals

    AC-C8T
    • Effective frequency range: 52 Hz – 20 kHz
    • Rated noise power / voltage: 80 watts / 25.3 volts (rms)
    • Broad-band sensitivity: 89 dB SPL
    • Coverage angle (-6 dB): 100° (500 Hz to 5 kHz)
    • Maximum continuous SPL: 108 dB
    • Maximum peak SPL: 114 dB
    • Rated impedance: 8 ohms
    • Transformer taps: 70 V: 60, 30, 15, 7.5, 3.8 watts and 8-ohm bypass
    • Transformer taps: 100V: 60, 30, 15, 7.5 watts and 8-ohm bypass
    • HF Transducer: 22 mm [.86-inch] silk dome tweeter, coaxially mounted
    • LF Transducer: 210 mm [8-inch] Polypropylene cone with butyl rubber surround
    • Input connector type: Euroblock connector with parallel output terminals
CONTENTS
    • (1) QSC AcousticCoverage Ceiling Loudspeaker
    • (1) Owner's Manual
