DESCRIPTION

The CX Series is designed to meet the specialized needs of sound contractors. Eight 2-channel models have been designed from the ground up, combining the exclusive QSC PowerLight™ technology with specific features to meet the requirements of fixed installations.

With high-output power, versatile loading options, high thermal capacity, and unmatched reliability, the CX Series is the perfect solution to any permanently installed sound system.

FEATURES
    • Exclusive PowerLight switch-mode power supply technology for high performance and compact size
    • Custom integrated security cover for tamper proof installations
    • Variable speed fan for low noise
    • 1-dB detented gain controls for fast and accurate gain settings
    • Active inrush limiting eliminates AC inrush current, removing the need for expensive power sequencers
    • XLR and detachable Euro style input connectors
    • HD15 DataPort connector for Q-SYS networked control and monitoring
    • Dip switch control for clip limiters, high pass filters, bridge mono and parallel operation
    • Selectable high pass filters protect speakers and prevent speaker transformer saturation with minimal effect on program material (33 Hz or 75 Hz)
    • Comprehensive front panel indicators including signal, clip, protect and QSC's exclusive bridge mono and parallel input LEDs
    • Barrier strip output connector
    • Comprehensive protection circuitry including DC, infrasonic, thermal overload and short circuit protection
    • Optional external transformer accessory pack for isolated 25-, 70-, and 100-volt outputs
    • Compact size - only 2 rack units high and 14" deep for reduced rack cost and floor space
    • Lightweight - weighs only 21 pounds (9.5 kg) for easier racking and shipping
    • 3-year warranty plus optional 3-year extended service contract
    • All CX Series amplifiers meet the European Union's 2006 RoHS directive to restrict the use of hazardous materials used in electronic devices.
    • Class H complementary bipolar output circuitry for high efficiency
SPECIFICATIONS
    • Power Rating, 8 ohms, 20 Hz-20 kHz, 0.05% THD: 550 W
    • Power Rating 4 ohms, 20 Hz-20 kHz, 0.05% THD: 900 W
    • Power Rating 2 ohms, 1 kHz, 1% THD: 1500 W
    • Power Rating, 70V, 20 Hz–20 kHz, 0.05% THD: 400 W
    • Power Rating, 70 V, 1 kHz, 0.05% THD: 440 W
    • Power Rating, 70 V, 1 kHz, 1% THD: 600 W
    • Power Rating, 16 ohms, 20 Hz-20 kHz, 0.1% THD: 1100 w
    • Power Rating, 8 ohms, 20 Hz-20 kHz, 0.1% THD: 2000 W
    • Power Rating, 4 ohms, 1 kHz, 1% THD: 3000 W
    • Power Rating, 140 V, 20 Hz–20 kHz, 0.05% THD: 800 W
    • Power Rating, 140 V, 1 kHz, 0.05% THD: 880 W
    • Power Rating, 140 V, 1 kHz, 1% THD: 1200 W
    • Noise, 20 Hz-20 kHz: -106 dB
    • Input Sensitivity @ 8 ohms: 1.17 Vrms
    • Voltage Gain @ 8 ohms: 35 dB
    • Output Circuitry: H, 2-tier
    • Distortion (SMPTE-IM): Less than 0.02%
    • Distortion (Typical) 20 Hz-20 kHz: 10 dB below rat: Less than 0.01% THD
    • Distortion (Typical) 1.0 kHz and below: full rated: Less than 0.01% THD
    • Frequency Response: 20 Hz-20 kHz, +/- 0.2 dB
    • Damping Factor: Greater than 500
    • Input Impedance: 6k ohms unbalanced, 12k ohms balanced
    • Input Clipping: 10 Vrms (+22 dBu)
    • Cooling: Variable-speed fan, rear-to-front air flow
    • Input Connectors, each channel: 3-pin XLR & 3-pin detachable terminal blocks (1 each per channel)
    • Output Connectors, each channel: Safety-shrouded barrier strip
    • Amplifier Protection: Full short circuit, open circuit, thermal, ultrasonic, and RF protection. Stable into reactive or mismatched loads.
    • Load Protection: On/Off muting, DC-fault power supply shutdown
    • Dimensions: 19" (48.3 cm) wide, 3.5" (8.9 cm) tall (2 RU), 14" (35.6 cm) deep (from front mounting rails)
    • Weight: 21 lbs (9.5 kg) net, 27 lbs (12.3 kg) shipping
CONTENTS
    (1) QSC CX902 2-Channel Power Amplifier
    (1) User's Manual
    (1) IEC Cable
    (1) Integrated security cover for tamper-proof installations
