Allen & Heath ZED60-10FX Mixer
Allen & Heath ZED60-10FX Mixer
19%, only 0 left
Allen & Heath ZED60-10FX Mixer
Allen & Heath ZED60-10FX Mixer
Product SKU
    27514

Allen & Heath ZED60-10FX Mixer

$479.99

PICK UP TODAY

recertified+.png__PID:7672a0bd-1cf7-4ba8-9841-5171b10f1ebf
  • Like New Condition
  • Original Packaging
  • Full Factory Warranty

Have a question?

Need help finding something?

Talk to a PRO

855-772-2937

_EBP9032_SQ.jpeg__PID:828e756e-5126-4f82-9136-2bf92b17727c

Expertly tested refurbished and open box products

Backed by the BYFP satisfaction guarantee

Copy of Untitled Design (3).png__PID:0d4aaa6e-815d-4b5a-879b-7bd16634732b

Free Shipping

1.png__PID:3c5bc891-9c7e-4dda-94a6-30ba47708c69

Professionally Inspected

2.png__PID:5bc8919c-7ecd-4a14-a630-ba47708c69eb

Satisfaction Guaranteed

3.png__PID:c8919c7e-cdda-44a6-b0ba-47708c69eb73

Expert Support

DESCRIPTION



Live or in the studio, ZED60-10FX is an ultra-portable mixer for solo artists and small bands.

Based on our top selling ZED-10FX, the new ZED60-10FX adds premium quality 60mm faders for that intuitive, tactile mixing experience.

This mixer is a guitarist's dream. Two of the 4 mono channels have high impedance jack inputs that can take a normal line level or a low level input from a guitar pickup, so guitars can be plugged straight into the mixer without the need for DI boxes. These inputs have been crafted to recreate the sound of a classic tube preamp in a combo or head amp for incredible definition and warmth. Two stereo inputs are provided for MP3/CD players or keyboards.

ZED60-10FX comes with configurable USB audio in/out, making it easy to capture a stereo recording at the gig or in the studio. The mixer is equipped with professional XLR main stereo outputs, a flexible monitoring section with headphone and speaker feed outputs, and 16 stunning FX.

Most important of all, ZED60-10FX lives up to the audio and build quality standards that have made Allen & Heath one of the most trusted names in professional audio for more than 40 years.



FEATURES
    • 4 mic/line inputs, 2 with Class A FET high impedance
    • 60mm professional quality faders
    • Responsive 3-band, swept mid EQ with MusiQ
    • Configurable USB stereo audio in/out
    • 2 stereo inputs
    • Separate 2-track record outputs
    • 16 Internal Effects
    • XLR main stereo outputs with inserts
    • Comprehensive monitoring
    • 48V microphone phantom power
    • DI level switching with Gain Boost
    • Neutrik XLRs and 1/4 inch jacks
SPECIFICATIONS
    • Mono channel (XLR) Input: -10 to --60dBu for nominal (+11dBu in max)
    • Mono channel Line Input (Jack socket): +10 to --40dBu (+31dBu maximum)
    • Stereo Input (Jack or phono sockets): 0dBu nominal (control = Off to +15dB)
    • L/R Outputs ( XLR) Normal/DI out: 0dBu/-30dBu +21dBu/-9dBu maximum.
    • Aux & FX Outputs (Jack sockets): 0dBu nominal. +21dBu maximum.
    • Record & Monitor Outputs (phono sockets): 0dBu nominal. +21dBu maximum.
    • Frequency Response, Mic in to Mix L/R Out, 30dB ga: +0.5/-1dB 10Hz to 30kHz
    • Frequency Response, Line in to Mix L/R out 0dB gai: +0.5/-1dB 10Hz to 25kHz
    • Frequency Response, Stereo in to Mix L/R out: +0.5/-1dB 10Hz to 30kHz
    • THD+n, Mic in to Mix L/R Out, 10dB gain 1kHz +10dB: 0.002%
    • THD+n, Mic in to Mix L/R Out, 30dB gain 1kHz: 0.01%
    • THD+n, Line in to Mix L/R out 0dB gain 0dBu 1kHz: 0.003%
    • THD+n, Stereo in to Mix L/R out 0dB gain +10dBu 1k: 0.002%
    • THD+n, Gtr Input to Mix L/R Out, 0dBu, Boost OUT: 0.015%
    • THD+n, Gtr Input to Mix L/R Out, 0dBu, Boost IN: 2% Second Harmonic
    • Analogue Headroom from nominal (0Vu): 21dB
    • USB in & out headroom from nominal (0Vu): 14dB
    • USB Audio In/Out: USB 1.1 compliant 16bit.
    • USB Audio Sample Rate: 32, 44.1, or 48kHz
CONTENTS
    (1) Allen & Heath ZED60-10FX Audio Mixer
    (1) IEC Power Cord
