DESCRIPTION

The AcousticDesign™ series offers integrators a premium-quality installed sound solution where performance, consistent coverage, and aesthetics are paramount. Specifically designed to maintain a consistent tonal characteristic across the entire family in ceiling, surface, and pendant applications, the AcousticDesign Series allows integrators seamless transitions within blended installations.

To further speed the install process while obtaining optimal results, Intrinsic Correction™ voicings are easily deployed via the Q-SYS Platform and CXD Series amplifiers as part of a complete QSC Systems solution.

FEATURES
    • Consistent tonal characteristics across the entire AcousticDesign family in surface, ceiling, and pendant applications
    • DMT (Directivity Matched Transition™) waveguide ensures smooth, uniform frequency response over the coverage area
    • Snap-fit magnetic grille
    • 2x quick-link suspension cables and slip-lock fasteners provided
    • Intrinsic Correction™ voicings available via Q-SYS Q-SYS Platform and CXD amplifiers
    • Low-saturation and low-loss 70/100V transformers with 16O bypass
    • Blemish-free removable logo
SPECIFICATIONS
    • Effective Frequency Range: 65 Hz – 20 kHz
    • Rated Noise Power/Voltage: 30 watts / 22 volts (rms)
    • Rated coverage (-6 dB): 150° conical DMT™
    • Directivity Factor: 4.5
    • Directivity index [dB]: 6.5
    • Maximum continuous SPL [dB]: 102
    • Maximum peak SPL [dB] 5: 108
    • Nominal impedance [ohms]: 16
    • Recommended Amplifier: 60 Watts
    • Transformer taps / impedance: 16O (in bypass setting). 3.75W (70V); 7.5W (100V). Tap: 1333O. 7.5W (70V); 15W (100V). Tap: 667O. 15W (70V); 30W (100V). Tap: 333O. 30W (70V); N/A (100V) Tap: 167O
    • LF Transducer: 114 mm [4.5 in] weather treated paper cone woofer
    • HF Transducer: 19 mm [0.75" in] aluminum dome tweeter
    • Input Connector Type: Euroblock connector with parallel output
    • Enclosure material: Impact Resistant ABS
    • Grille material: Powder coated steel
    • Ingress protection: IP-34
    • Operating environment: Designed for indoor use
    • Product Weight: 6.5 lb
    • Product Dimension (D x H): 9.3" x 10.7"
    • Safety Agency: UL1480, Transformer UL registered per UL1876, ROHS, CE compliant. Baffle meets UL94-V0 and UL94-5VB flammability rating; in accordance with IEC60849 / EN60849 systems
CONTENTS
    (1) QSC Acoustic 4.5" Design Pendant-Mount Loudspeaker
    (1) User's Manual
    (1) Mounting Hardware
