DESCRIPTION

The Radial SGI Studio Guitar Interface is a transmit (SGI-TX) and receive (SGI-RX) pair of modules that allows a guitar signal to travel across 300 feet of balanced cable to a distant amplifier. The SGI is a unity gain device that features 100% discrete Class-A circuitry for great sound and transformer isolation to eliminate ground loops.

FEATURES
    • Balanced line driver for guitar and bass
    • Send signal up to 100 meters (300ft) without loss
    • 100% discrete class-A circuit with Drag control
    • Delivers natural tone to off-stage amplifiers
SPECIFICATIONS
    • Audio Circuit Type: Active 100% discrete class-A with transformer isolation
    • Frequency Response: 20Hz ~ 18kHz (-2dB)
    • Dynamic Range: 112dB
    • Total Harmonic Distortion: 0.005% @ 1k
    • Intermodulation Distortion: 0.04% @ 1k
    • Input Impedance: Variable from 10k Ohms ~ 1 megaOhm
    • Output Impedance: 4.5k Ohms (¼" unbalanced)
    • Noise Floor: -102dBu
    • Maximum Input: +10dBu
    • Construction: 14-gauge steel chassis & outer shell
    • Power: +15VDC/400mA adapter included
    • Product Dimensions (L x W x D): 2.75" x 4.25" x 1.75" (70 x 108 x 44 mm)
    • Weight: 3 lb
    • Conditions: For use in dry locations only between 5°C and 40°C
    • Warranty: Radial 3-year, transferable
CONTENTS
    (1) Radial Guitar Interface System - TX Transmitter
    (1) User Manual
