DESCRIPTION

The SGI-44™ is a line driver for guitars and basses that connects to the JX-44 to allow a remote pedalboard to be connected without signal loss or noise.

FEATURES
    • Balanced line driver for JX-44 guitar & amp switcher
    • Send signal over 100 meters (300ft) without loss
    • 100% discrete class-A circuit with Drag control
    • Bidirectional send & receive effects router
SPECIFICATIONS
    • Audio Circuit Type: Active 100% discrete class-A with transformer isolation
    • Frequency Response: 20Hz ~ 20kHz (-2dB)
    • Dynamic Range: 105dB
    • Total Harmonic Distortion: 0.005% @ 1k
    • Intermodulation Distortion: 0.02% @ 1k
    • Input Impedance: Variable from 10k Ohms ~ 1 megaOhm
    • Output Impedance: 218 Ohms (¼" unbal. output); 280 Ohms (TX bal. output)
    • Noise Floor: -100dBu
    • Maximum Output: +2dBu
    • Features: Ground lift, Drag Control
    • Connectors: 1/4", XLR
    • Construction: 14-gauge steel chassis & outer shell
    • Product Dimensions (L x W x D): 4.25" x 2" x 5" (102 x 76 x 165 mm)
    • Porduct Weight: 3 lb
    • Power: +15VDC/400mA adapter included
    • Conditions: For use in dry locations only between 5°C and 40°C
    • Warranty: Radial 3-year, transferable
CONTENTS
    (1) Radial SGI-44 Guitar Signal Extender
    (1) User Guide
