Roland VC-1-SC Video Converter

$799.99

PICK UP TODAY

recertified+.png__PID:7672a0bd-1cf7-4ba8-9841-5171b10f1ebf
  • Like New Condition
  • Original Packaging
  • Full Factory Warranty

Have a question?

Need help finding something?

Talk to a PRO

855-772-2937

_EBP9032_SQ.jpeg__PID:828e756e-5126-4f82-9136-2bf92b17727c

Expertly tested refurbished and open box products

Backed by the BYFP satisfaction guarantee

Copy of Untitled Design (3).png__PID:0d4aaa6e-815d-4b5a-879b-7bd16634732b

Free Shipping

1.png__PID:3c5bc891-9c7e-4dda-94a6-30ba47708c69

Professionally Inspected

2.png__PID:5bc8919c-7ecd-4a14-a630-ba47708c69eb

Satisfaction Guaranteed

3.png__PID:c8919c7e-cdda-44a6-b0ba-47708c69eb73

Expert Support

DESCRIPTION

Roland's new video converters address the demand for high-quality, lossless video and audio converters for live/post production as well as installed systems. They include the Roland VC-1-HS (HDMI to SDI), VC-1-SH (SDI to HDMI), and VC-1-DL (Bi-directional SDI/HDMI with audio/video delay and frame sync).

The VC-1 Video Converter series provides uncompromising picture quality by maintaining the video characteristics of the original signal with rich-blacks and super-whites. There are no interlacing artifacts or other conversion or signal errors sometimes found with other video converters. The VC-1 series also features an on-board re-clocker to compensate for attenuation of SDI signals carried over long distances. The VC-1 series also supports both level A and B 3G-SDI, letting you connect a variety of higher quality SDI sources.

The VC-1 series is HDCP compliant allowing you to convert or pass-through HDCP signals with the exception of any SDI output. The VC-1-DL additionally enables the HDCP signal to be delayed. Selectable audio embedding and de-embedding lets you route different audio sources to or from video devices. Digital AES/EBU input and output signals are supporting ensuring high-quality audio signals can be maintained through the signal flow.

FEATURES
    • Up/Down/Cross Scan Converter to/from SDI/HDMI
    • Lossless Image Conversion
    • 3G (Level A&B)/HD/SD SDI
    • HDCP Support
    • VC-1 RCS, PC/Mac Control Application
    • Selectable Channel for Embedded/De-Embedded Audio
SPECIFICATIONS
    • Input SDI Connector: BNC type x 1
    • Input HDMI Connector: Type A (19 pins) x 1
    • Input Analog Audio Connector: RCA phono type x 1 pair (L/R)
    • Reference Connector: BNC type x 1
    • Processing: Audio embedding, Audio de-embedding, Frame Synchronize, Resolution Conversion, Frame Rate Conversion
    • Output SDI Connector: BNC type x 1
    • Output HDMI Connector: Type A (19 pins ) x 1
    • Output Analog Audio Connector: RCA phono type x 1 pair ( L/R)
    • SDI Format: Connector: BNC type x 1 (Combined use with SDI Out Connector) Signal Standards: SMPTE 424M (SMPTE 425M-AB), SMPTE 292M, SMPTE 259M-C Video Format: 1920x1080/60p/59.94p/50p/30p/29.97p/25p/24p/23.98p/60i/59.94i/50i,1920x1080/30PsF/29.97PsF/25PsF/24PsF/23.98PsF (Conforms to SMPTE 274M) 1280x720/60p/59.94p/50p/30p/29.97p/25p/24p/23.98p (Conforms to SMPTE 296M) 720x480/59.94i, 720x576/50i (Conforms to ITU-R BT.601-5) Color Format : 10 bits YCC 4:2:2 Audio Format: Linear PCM, 24 bits, 48 kHz, 16 ch (Conforms to SMPTE 299M, SMPTE 272M-C) When f...0/60Hz, 1600x1200/60Hz, 1920x1200/60Hz Reduced blanking (Conforms to VESA DMT Version 1.0 Revision 11)
    • Composite Format: NTSC, PAL
    • HDMI Format: Video Format: 1920x1080/60p/59.94p/50p/30p/29.97p/25p/24p/23.98p/60i/59.94i/50i, 1280x720/60p/59.94p/50p/30p/29.97p/25p/24p/23.98p, 720x480/59.94p/59.94i, 720x576/50p/50i (Conforms to CEA-861-E) PC Format: 640x480/60/72/75/85Hz, 800x600/56/60/72/75/85Hz, 1024x768/60/70/75/85Hz, 1280x768/60/75/85/Hz, 1360x768/60Hz, 1152x864/75Hz, 1400x900/60/75/85Hz, 1280x960/60/85Hz, 1280x1024/60/75/85Hz, 1400x1050/60/75Hz, 1680x1050/60Hz, 1600x1200/60Hz, 1920x1200/60Hz Reduced blanking (Conforms to VESA DMT Version 1.0 Revision 11) Color Format: 10 bits YCC 4:2:2, 8 bits YCC 4:4:4, 8 bits RGB 4:4:4 Audio Format: Linear PCM, 24 bits, 48 kHz, 8 ch
    • USB Connector: USB Type B (Hi-Speed USB) x 1
    • Power Supply: DC 9V
    • Dimensions: 5 15/16" (150 mm) x 5 1/8" (130 mm) x 1 3/16" (30 mm)
    • Weight: 1 lb 2 oz (500 g)
    • Input RGB/Component Connector: HD DB-15 type
CONTENTS
    (1) Roland VC-1-SC Scan Converter
    (1) AC Adaptor
    (1) Power Cord
