Product SKU
    26140

Allen & Heath dLive S5000 Mixing Surface

$28,199.99

PICK UP TODAY

recertified+.png__PID:7672a0bd-1cf7-4ba8-9841-5171b10f1ebf
  • Like New Condition
  • Original Packaging
  • Full Factory Warranty

Have a question?

Need help finding something?

Talk to a PRO

855-772-2937

_EBP9032_SQ.jpeg__PID:828e756e-5126-4f82-9136-2bf92b17727c

Expertly tested refurbished and open box products

Backed by the BYFP satisfaction guarantee

Copy of Untitled Design (3).png__PID:0d4aaa6e-815d-4b5a-879b-7bd16634732b

Free Shipping

1.png__PID:3c5bc891-9c7e-4dda-94a6-30ba47708c69

Professionally Inspected

2.png__PID:5bc8919c-7ecd-4a14-a630-ba47708c69eb

Satisfaction Guaranteed

3.png__PID:c8919c7e-cdda-44a6-b0ba-47708c69eb73

Expert Support

DESCRIPTION

The Allen & Heath dLive S5000 Surface is a sophisticated digital mixing console designed for professional audio engineers. It features a large, responsive 20.5-inch touchscreen and 28 assignable faders, providing a highly customizable and intuitive interface for managing complex live sound environments. The S5000 boasts 128 input channels and 64 configurable output busses, ensuring versatility for any live event. Its advanced DEEP processing architecture allows for precise control over EQ, compression, and effects without latency, while the integrated networking options support a wide range of audio protocols, making it ideal for large-scale productions, touring, and broadcast applications. The robust build quality and ergonomic design further enhance its suitability for demanding live sound applications, ensuring reliability and ease of use under pressure.

FEATURES
    • Fully assignable layout
    • Harmony UI – integrated screen and ‘wrap-around’ controls
    • Single or twin 12” capacitive touchscreen
    • Gesture control – pinch, swipe, drag ‘n drop
    • Configurable widget areas for Scenes, meters, FX and more
    • 3 pages of assignable rotaries per screen
    • 26 assignable SoftKeys
    • Engineer’s Wedge and IEM fader strips
    • Comprehensive multipoint metering
    • Daylight visibility
    • USB stereo recording and playback
    • Dual redundant, hot swappable power supply
SPECIFICATIONS
    • Mic/Line XLR Inputs: Balanced XLR, +48V phantom power
    • Mic/Line Preamp: Fully recallable
    • Input Sensitivity: -60 to +15dBu
    • Analogue Gain: +5 to +60dB, 1 dB steps
    • Pad: -20dB active PAd
    • Maximum Input Level: +30dBu (PAD in)
    • Input Impedance: >4kOhms (Pad out), >10kOhms (Pad in)
    • Mic ein: -127dB with 150Ohms source
    • Phantom Power Indication: Per socket, internal or external phantom power sensing, triggered at 24V
    • Dynamic Range: 110dB
    • System Signal to Noise: -92dB
    • Frequency Response: 20Hz - 30kHz +0/-0.8dB
    • THD+N (Analogue In to Out): 0.0015% @ +16dBu output, 1kHz 0dB gain
    • Headroom: +18dB
    • Internal Operating Level: 0dBu
    • dBFS Alignment: +18dBu = 0dBFS (+22dBu at XLR output)
    • Meter Calibration: 0dB meter = -18dBFS (+4dBu at XLR out)
    • Digital Input Meter Indication: -3dBFS (+19dBu at XLR out)
    • Analogue XLR Outputs: Balanced, Relay Protected
    • Output Impedance: <75 Ohms
    • Nominal Output: +4dBu = 0dB meter reading
    • Maximum Output Level: +22dBu
    • Residual Output Noise: -92dBu (muted, 20-20kHz)
    • Residual Output Noise: -90dBu (muted, 20-40kHz)
    • Latency: 0.7ms (MixRack XLR in to XLR out, Input to Mix)
    • Latency: + 5 samples, Surface to Mixrack (GigaACE hop)
    • Latency: + 8 samples, DX32 to Mixrack (DX hop)
    • Digital Outputs: AES3 2 Ch XLR, 2.5Vpp balanced terminated 110 Ohms
CONTENTS
    (1) Allen & Heath dLive S5000 Mixing Surface
    (1) Getting Started Guide AP9899
    (1) Safety Sheet
    (1) IEC mains lead
    (1) Dust Cover
