Chauvet Maverick MK Pyxis

Product Short Title
    Maverick MK Pyxis is a Versatile and Innovative Moving Head Fixture
$2,000.00

PICK UP TODAY

Quick & Complimentary Shipping

1.png__PID:7af1a3fd-a98e-4384-a357-aae772061f43

FREE SHIPPING

2.png__PID:f1a3fda9-8e83-44e3-97aa-e772061f434b

EXPERT SUPPORT

Copy of Untitled Design.png__PID:a98e8384-e357-4ae7-b206-1f434b4f7c25

HASSLE FREE RETURNS

Have a question?

Need help finding something?

Talk to a PRO

855-772-2937

_EBP8997_SQ_1.png__PID:e7077992-36de-44a6-a734-ae2d97143238

Related Products

BYFP ipCase for 12x PGA57/58 Wired Microphones
BYFP ipCase for 12x PGA57/58 Wired Microphones
BYFP ipCase for 12x PGA57/58 Wired Microphones
BYFP ipCase for 12x PGA57/58 Wired Microphones
BYFP ipCase for 12x PGA57/58 Wired Microphones
BYFP ipCase for 12x PGA57/58 Wired Microphones
BYFP ipCase for 12x PGA57/58 Wired Microphones
BYFP ipCase for 12x PGA57/58 Wired Microphones
BYFP ipCase for 12x PGA57/58 Wired Microphones
BYFP ipCase for 12x PGA57/58 Wired Microphones

BYFP ipCase for 12x PGA57/58 Wired Microphones

$149.99
BYFP ipCase for Shure SM7B Broadcast Pack
BYFP ipCase for Shure SM7B Broadcast Pack
BYFP ipCase for Shure SM7B Broadcast Pack
BYFP ipCase for Shure SM7B Broadcast Pack
BYFP ipCase for Shure SM7B Broadcast Pack
BYFP ipCase for Shure SM7B Broadcast Pack
BYFP ipCase for Shure SM7B Broadcast Pack
BYFP ipCase for Shure SM7B Broadcast Pack
BYFP ipCase for Shure SM7B Broadcast Pack
BYFP ipCase for Shure SM7B Broadcast Pack
BYFP ipCase for Shure SM7B Broadcast Pack
BYFP ipCase for Shure SM7B Broadcast Pack

BYFP ipCase for Shure SM7B Broadcast Pack

$349.99
BYFP ipCase for Beta 52A and Beta 91A Drum Microphone
BYFP ipCase for Beta 52A and Beta 91A Drum Microphone
BYFP ipCase for Beta 52A and Beta 91A Drum Microphone
BYFP ipCase for Beta 52A and Beta 91A Drum Microphone
BYFP ipCase for Beta 52A and Beta 91A Drum Microphone
BYFP ipCase for Beta 52A and Beta 91A Drum Microphone
BYFP ipCase for Beta 52A and Beta 91A Drum Microphone
BYFP ipCase for Beta 52A and Beta 91A Drum Microphone
BYFP ipCase for Beta 52A and Beta 91A Drum Microphone
BYFP ipCase for Beta 52A and Beta 91A Drum Microphone
BYFP ipCase for Beta 52A and Beta 91A Drum Microphone
BYFP ipCase for Beta 52A and Beta 91A Drum Microphone
BYFP ipCase for Beta 52A and Beta 91A Drum Microphone
BYFP ipCase for Beta 52A and Beta 91A Drum Microphone

BYFP ipCase for Beta 52A and Beta 91A Drum Microphone

$179.99
BYFP ipCase for Shure BETA 98AMP/C 3-Pack
BYFP ipCase for Shure BETA 98AMP/C 3-Pack
BYFP ipCase for Shure BETA 98AMP/C 3-Pack
BYFP ipCase for Shure BETA 98AMP/C 3-Pack
BYFP ipCase for Shure BETA 98AMP/C 3-Pack
BYFP ipCase for Shure BETA 98AMP/C 3-Pack
BYFP ipCase for Shure BETA 98AMP/C 3-Pack
BYFP ipCase for Shure BETA 98AMP/C 3-Pack
BYFP ipCase for Shure BETA 98AMP/C 3-Pack
BYFP ipCase for Shure BETA 98AMP/C 3-Pack
BYFP ipCase for Shure BETA 98AMP/C 3-Pack
BYFP ipCase for Shure BETA 98AMP/C 3-Pack
BYFP ipCase for Shure BETA 98AMP/C 3-Pack
BYFP ipCase for Shure BETA 98AMP/C 3-Pack

BYFP ipCase for Shure BETA 98AMP/C 3-Pack

$169.99
Maverick MK Pyxis empowers your creativity by giving you an endless array of incredible eye-candy looks with its epic beam and wash effects, wide zoom range, continuous 360° pan and tilt movement and awesome aerial and pixel-mapping effects. This revolutionary and compact moving head features a ring of nine 15 W RGBW LEDs with a zoom range of 4.9° to 58.4° and built in color macros and gobos, as well as a punchy 60 W RGBW LED serving as a center pixel with a 3° beam angle. Choose from DMX, sACN, Art-Net, or W-DMX for control.
FEATURES
    • A full featured RGBW LED wash and beam fixture with 360° continuous pan and tilt movement
    • A (9) 15 W RGBW LED outer ring of LEDs with a 4.9°— 58.4° zoom range and pixel control for wash and narrow effects
    • A single 60 W RGBW LED center pixel with a fixed 3° beam angle for dedicated beam color effects
    • Virtual Color wheel with instantaneous access to 21 colors
    • Built in color effects for quick design possibilities
    • Built in virtual gobo wheel with background colors for impressive atmospheric effects
    • Quiet operation for a wide range of installation situations
    • DMX, W-DMX, S ACN, Art-Net, and Kling-Net control for full flexibility
    • RDM enabled for remote addressing and trouble shooting
    • Converts TCP/IP to DMX for shorter data cable runs
    • 2.8°— 58.4° zoom range for variable beam sizes
    • True 1 compatible power input
    • Battery backup touchscreen display with auto rotate depending on fixture orientation
    • Three setup menu presets and preset sync for cross loading to multiple like fixtures for easy shop setup
SPECIFICATIONS
    OPTICAL
    • Light Source: 9 LEDs outer ring (quad-color RGBW) 15 W, (1.29 A), 50,000 hours life expectancy
    • Light Source: 1 LED center pixel (quad-color RGBW) 60 W, (4.5 A), 50,000 hours life expectancy
    • Color Temperature (Range): 2,800 to 10,000 K
    • Beam Angle (Center Pixel and Outer Ring): 2.8°
    • Beam Angle (Center Pixel): 2.7°
    • Beam Angle (Outer Ring): 4.9° to 32°
    • Field Angle (Center Pixel and Outer Ring): 6.7°
    • Field Angle (Center Pixel) 4.5°
    • Field Angle (Outer Ring): 7.9° to 47.8°
    • Cutoff Angle: 8.3° to 58.4°
    • Zoom Range: 4.9° to 58.4°
    • Lumens – Source (Center Pixel): 1,700 (outer ring) 4,300
    • Lumens – Output (Center Pixel): 1,100 (outer ring) 2,400
    • Illuminance (Center Pixel / Outer Ring): 11,267 lux @ 5 m
    • Illuminance (Center Pixel): 19,306 lux @ 5 m
    • Illuminance (Outer Ring): (7.9°) 4,724 lux @ 5 m, (47.8°) 437 lux @ 5 m
    • Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 15,000 Hz

    DYNAMIC EFFECTS
    • Pan and Tilt: 540°/270°
    • Pan and Tilt Ranges: Infinite, 540°, 360°, 180° pan/ Infinite, 270°, 180°, 90° tilt
    • Dimmer: Electronic
    • Shutter/Strobe: Electronic
    • Zoom: Motorized
    • Strobe Rate: 0 to 20 Hz
    • Color Temperature Presets: Yes
    • Move-in-Black: Yes
    • Dim Modes: 2
    • Dim Curves: 4

    CONNECTIONS
    • Power Connection: Edison plug to Seetronic Powerkon IP65
    • Power Input/Output: Seetronic Powerkon IP65
    • Data Connectors: 3- and 5-pin XLR, , Amphenol XLR Net RJ45 Connectors in/out
    • Cable Length (Power): 5 ft (1.5 m)

    CONTROLS
    • Control Protocol: Art-Net, sACN, Kling-Net, DMX, W-DMX, RDM
    • DMX Channels Single Mode: 26,66,113,131
    • DMX Channels Dual Mode – Function: 13,26,33
    • DMX Channels Dual Mode – Pixel: 30,40,80
    • Art-Net Channels Single Mode: 26,66,113,131
    • Art-Net Channels Dual Mode – Function: 13,26,33
    • Art-Net Channels Dual Mode – Pixel: 30,40,80

    ELECTRICAL
    • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
    • Power Linking: 4 units @ 120 V;7 units @ 208 V; 8 units @ 230 V
    • Power and Current: 325 W, 2.726 A @ 120 V, 60 Hz
    • Power and Current: 322 W, 1.546 A @ 208 V, 60 Hz
    • Power and Current: 321 W, 1.395 A @ 230 V, 50 Hz

    CERTIFICATION/QUALIFICATIONS:
    • CE and IP Rating: IP20, dry location
CONTENTS
    (1) Chauvet Professional Maverick PYXIS
    (1) Seetronic Powerkon IP65 power cord
    (1) Omega Bracket with Mounting Hardware
