Spin out with continuous 360 degree rotation. Stand out with a Mint-powered RMB light engine that sets Rogue Outcast 1M Beam apart from the rest of the pack by offering a multi-color LED solution and great optics to produce sharp beams of the highest quality white light and your choice of color. A compact beam fixture that weighs in under thirty pounds, designed to deliver fast and precise performance as well as easy event setups. Create stunning aerial effects with dual overlapping prisms or instantly punch up pencil-thin beams with a selection of aperture gobos. IP65-rated and ready to go anywhere, Rogue Outcast 1M Beam handles outdoor use as well as it handles haze, dust, confetti and other elements in permanent indoor installations with minimum need for upkeep.
• Fully featured, high powered IP65 rated beam fixture with a Red, Mint and Blue LED, single gobo wheel with static gobos, layerable prisms in a lightweight and durable aluminum / magnesium casing
• Full color mixing from the LED source for a wide spectrum of color variations. No color wheel needed
• 360° pan and tilt movement for endless movement effects
• Fast and precise movement of pan and tilt functions
• Individually controllable and layerable 6- and 8-facet prisms
• Frost for even light distribution
• 5-pin DMX input/output connections
• RDM enabled for remote addressing and troubleshooting
• Tight 1.9° beam for extremely focused aerial effects
• 17 static gobos on one wheel for dynamic gobo effects
• Simple and complex DMX channel profiles for programming versatility
• USB-C port for uploading software
• Easy to read OLED display with simple, effective menu options
OPTICAL
• Light Source: 1 LEDs (Red,Mint,Blue) 120 W, (3.34A), 50,000 hours life expectancy
• Color Temperature (At Full): 10,398 K
• Front Lens Diameter: 140 mm
• CRI: 80.8
• Beam Angle: 1.9°
• Field Angle: 2.7°
• Cutoff Angle: 3.4°
• Lumens – Output: 4,488
• Illuminance (Total): 117,690 lux @ 5 m
DYNAMIC EFFECTS
• Pan and Tilt: 360°/360° total movement
• Pan and Tilt Ranges: 540°, 360°, 180° pan/270°, 180°, 90° tilt
• Gobos (1): 17 + open (metal), continuous scroll at variable speeds
• Gobo Size: Gobo Wheel (rotating): 6 mm (outside), .6 mm (max. thickness)
• Dimmer: Electronic
• Shutter/Strobe: Electronic
• Focus: Motorized
• Frost: Motorized
• Prism: 6 Facets, motorized, linear, rotating
• Prism: 8 Facets, motorized, round, rotating
• Strobe Rate: 0 to 30 Hz
CONSTRUCTION / PHYSICAL
• Dimensions: 11.9 x 7.56 x 17.9 in (302 x 192 x 455 mm)
• Weight: 27.2 lb (12.34 kg)
• Exterior Color: Black
• Housing Material: Aluminum/Magnesium diecast
CONNECTIONS
• Power Connection: Edison (Local) plug to Seetronic Powerkon IP65
• Power Input: Seetronic Powerkon IP65
• Data Connectors: 5-pin IP65 XLR
• Cable Length (Power): 5 ft (1.5 m)
CONTROL
• Control Protocol: DMX, RDM
• DMX Channels: 21 or 25
• Modes/Personalities: 2 personalities (21, 25)
ELECTRICAL
• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current: 232 W, 1.95 A @ 120 V, 60 Hz
• Power and Current: 223 W, 1.11 A @ 208 V, 60 Hz
• Power and Current: 220 W, .990 A @ 230 V, 50 Hz
• Certifications / Qualifications: CE, MET, FCC, UKCA
• IP Rating: IP65, outdoor/wet, with pressure equalizing M12 GORE valve
• Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)
(1) Chauvet Professional Rogue Outcast 1M Beam
(1) Seetronic Powerkon IP65 Power Cord
(1) 105mm Omega Bracket with Mounting Hardware
