DESCRIPTION
Ovation H-55FC is a small, silent, convection cooled LED houselight with a punchy, full color output and high CRI that makes it ideal for theaters, recital halls, worship venues, or any other application with a smaller trim height. The compact unit also features 16-bit dimming, RDM and W-DMX control as well as adjustable PWM to prevent flickering on televised performances. The interchangeable lenses are a must-have feature in theatrical and house of worship applications. The compact houselight also includes multiple mounting options with removable fixture yoke, a recess mounting, and a sconce mounting kit. White housing not available in European Markets.
FEATURES
    • H-55 FC
    • Compact, full color (RGBAL), convection cooled houselight
    • Interchangeable lens plates to adapt to different mounting heights
    • 5-pin XLR and terminal blocks for DMX connections
    • Use included yoke for mounting, or suspend from integrated loop-eye
    • Included recess and sconce mounting kits
    • 16-bit dimming for ultra-smooth fades
    • DMX, WDMX and RDM (Remote Device Management) for added programming flexibility
    • Adjustable PWM (Pulse Width Modulation) to avoid flickering on camera

    • H-55 WW
    • Compact, warm white, convection cooled house light
    • Interchangeable lens plates to adapt to different mounting heights
    • 5-pin XLR and terminal blocks for DMX connections
    • Use included yoke for mounting, or suspend from integrated loop-eye
    • Included recess and sconce mounting kits
    • 16-bit dimming for ultra-smooth fades
    • DMX, WDMX and RDM (Remote Device Management) for added programming flexibility
    • Adjustable PWM (Pulse Width Modulation) to avoid flickering on camera

SPECIFICATIONS
    • H-55 FC
    • OPTICAL:
    • Light Source: 26 LEDs (6 red, 6 green, 6 blue, 5 amber, 4 lime) 2.62 to 5.25 W (840 mA), 4807 K, 50,000 hours life expectancy.
    • Color Temperature (At Full): 4807 K
    • CRI (3200 K): 82
    • Beam Angle (w/80° filter): 46.1°
    • Beam Angle (w/65° lens): 63.3°
    • Beam Angle (w/45° lens): 38.8°
    • Beam Angle (w/25° lens): 24.7°
    • Field Angle (w/80° filter): 76.8°
    • Field Angle (w/65° lens): 86.9°
    • Field Angle (w/45° lens): 78.4°
    • Field Angle (w/25° lens): 46.7°
    • Illuminance (w/80° filter): 152 lux @ 5 m
    • Illuminance (w/65° lens): 115 lux @ 5 m
    • Illuminance (w/45° lens): 173 lux @ 5 m
    • Illuminance (w/25° lens): 430 lux @ 5 m
    • Lumens (w/80° filter): 2,698
    • Lumens (w/65° lens): 2,928
    • Lumens (w/45° lens): 2,691
    • Lumens (w/25° lens): 2,849
    • Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6000 Hz, 25,000 Hz

    • DYNAMIC EFFECTS:
    • Dimmer: Electronic
    • Shutter/Strobe: Electronic
    • Strobe Rate: 0 to 30 Hz
    • Color Temperature Presets: Yes/No
    • Dim Modes: 4
    • Built-in Automated Programs: Yes
    • CONSTRUCTION / PHYSICAL:
    • Dimensions: 13.14 x 6.92 x 4.52 in (334 x 176 x 115 mm)
    • Weight: 7.4 lb (3.4 kg)
    • Exterior Color: Black

    • CONNECTIONS:
    • Power Connection: Bare-wired
    • Power Input: Hard-wired
    • Data Connectors: 5-pin XLR, Phoenix connector
    • Cable Length (Power): 15 ft (4.5 m)

    • CONTROL:
    • Control Protocol: DMX, W-DMX, RDM
    • DMX Channels: 4, 5, 8, 11, 13, 14, 16 or HSV
    • Modes/Personalities: 8 personalities (2, 4, 5, 8, 11, 13, 14, 16, HSV)

    • ELECTRICAL:
    • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
    • Power and Current: 62 W, 0.541 A @ 120 V, 60 Hz
    • Power and Current: 64 W, 0.308 A @ 208 V, 60 Hz
    • Power and Current: 64 W, 0.278 A @ 230 V, 50 Hz
    • Certifications / Qualifications: CE, MET,
    • IP Rating: IP20, dry location
    • Temperature (Ambient): -4 °F to 113 °F (-10 °C to 45 °C)

    • H-55 WW
    • OPTICAL:
    • Light Source: 1 LEDs (WW) 129.5 W, (1.45 A), 3157 K, 50,000 hours life expectancy
    • Color Temperature (At Full): 3157 K
    • CRI (3200 K): 93
    • Beam Angle (w/80° filter): 41°
    • Beam Angle (w/65° lens): 39°
    • Beam Angle (w/45° lens): 30°
    • Beam Angle (w/25° lens): 24°
    • Field Angle (w/80° filter): 126°
    • Field Angle (w/65° lens): 73°
    • Field Angle (w/40° lens): 58°
    • Field Angle (w/25° lens): 39°
    • Illuminance (w/80° filter): 131 lux @ 5 m
    • Illuminance (w/65° lens): 212 lux @ 5 m
    • Illuminance (w/40° lens): 400 lux @ 5 m
    • Illuminance (w/25° lens): 728 lux @ 5 m
    • Lumens (w/80° filter): 3314
    • Lumens (w/65° lens): 3797
    • Lumens (w/40° lens): 4007
    • Lumens (w/25° lens): 4079
    • Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6000 Hz, 25,000 Hz

    • DYNAMIC EFFECTS:
    • Dimmer: Electronic
    • Shutter/Strobe: Electronic
    • Strobe Rate: 0 to 25 Hz
    • Color Temperature Presets: Yes/No
    • Dim Modes: 4
    • Built-in Automated Programs: Yes
    • CONSTRUCTION / PHYSICAL:
    • Dimensions: 13.14 x 6.92 x 4.52 in (334 x 176 x 115 mm)
    • Weight: 7.4 lb (3.4 kg)
    • Exterior Color: Black

    • CONNECTIONS:
    • Power Connection: Bare-wired
    • Power Input: Hard-wired
    • Data Connectors: 5-pin XLR, Phoenix connector
    • Cable Length (Power): 15 ft (4.5 m)

    • CONTROL:
    • Control Protocol: DMX, W-DMX, RDM
    • DMX Channels: 1, 2 or 5
    • Modes/Personalities: 3 personalities (1CH, 2CH, 5CH)

    • ELECTRICAL:
    • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
    • Power and Current: 60 W, 0.497 A @ 120 V, 60 Hz
    • Power and Current: 61 W, 0.297 A @ 208 V, 60 Hz
    • Power and Current: 63 W, 0.269 A @ 230 V, 50 Hz
    • Certifications / Qualifications: CE, MET, FCC
    • IP Rating: IP20, dry location
    • Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)



CONTENTS
    • (1) Chauvet Professional White Ovation H-55
    • (1) 65°, 40° and 25° Lens
    • (1) 80° Filter
    • (1) Egg Crate
    • (1) Recess and Sconce Mounting Kits
