Clear-Com Freespeak II Base Station
Clear-Com Freespeak II Base Station
Clear-Com Freespeak II Base Station
Clear-Com Freespeak II Base Station
Clear-Com Freespeak II Base Station
Clear-Com Freespeak II Base Station
Clear-Com Freespeak II Base Station
Clear-Com Freespeak II Base Station
0%, only 8 left
Clear-Com Freespeak II Base Station
Clear-Com Freespeak II Base Station
Clear-Com Freespeak II Base Station
Clear-Com Freespeak II Base Station
Clear-Com Freespeak II Base Station
Clear-Com Freespeak II Base Station
Clear-Com Freespeak II Base Station
Clear-Com Freespeak II Base Station

Clear-Com Freespeak II Base Station

    32581
['{"currentVariantId":"44361483419816","currentType":"single_line_text_field","currentKey":"variation_sku","currentProps":{"badgeWidth":28,"badgeHeight":28,"showDate":true,"dateFormat":"%m-%d-%Y","showTime":true,"timeFormat":"%I:%M %p","showTimezone":true,"showUnit":true,"showMaxScale":true,"trueValText":"TRUE","falseValText":"FALSE","linkToUrl":true,"linkText":null}}',[{"variation_sku":"32581"},{"id":54325727854760,"title":"5 Beltpacks \/ 4-Pin","option1":"5 Beltpacks","option2":"4-Pin","option3":null,"sku":"32581","requires_shipping":true,"taxable":true,"featured_image":{"id":48230448169128,"product_id":9176018124968,"position":1,"created_at":"2025-10-30T12:34:47-07:00","updated_at":"2025-10-30T12:35:52-07:00","alt":null,"width":2505,"height":2505,"src":"\/\/www.avbyfp.com\/cdn\/shop\/files\/FSII-Base---Front-Lights_Optimized.png?v=1761852952","variant_ids":[54325727854760,54325727887528,54325727920296,54325727953064]},"available":true,"name":"Clear-Com Freespeak II Base Station - 5 Beltpacks \/ 4-Pin","public_title":"5 Beltpacks \/ 4-Pin","options":["5 Beltpacks","4-Pin"],"price":872200,"weight":2722,"compare_at_price":null,"inventory_management":"shopify","barcode":"FSIIBASEII5","featured_media":{"alt":null,"id":37349344673960,"position":1,"preview_image":{"aspect_ratio":1.0,"height":2505,"width":2505,"src":"\/\/www.avbyfp.com\/cdn\/shop\/files\/FSII-Base---Front-Lights_Optimized.png?v=1761852952"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},], [{"variation_sku":"32582"},{"id":54325727887528,"title":"5 Beltpacks \/ 5-Pin","option1":"5 Beltpacks","option2":"5-Pin","option3":null,"sku":"32582","requires_shipping":true,"taxable":true,"featured_image":{"id":48230448169128,"product_id":9176018124968,"position":1,"created_at":"2025-10-30T12:34:47-07:00","updated_at":"2025-10-30T12:35:52-07:00","alt":null,"width":2505,"height":2505,"src":"\/\/www.avbyfp.com\/cdn\/shop\/files\/FSII-Base---Front-Lights_Optimized.png?v=1761852952","variant_ids":[54325727854760,54325727887528,54325727920296,54325727953064]},"available":true,"name":"Clear-Com Freespeak II Base Station - 5 Beltpacks \/ 5-Pin","public_title":"5 Beltpacks \/ 5-Pin","options":["5 Beltpacks","5-Pin"],"price":872200,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":"FSIIBASEII5X5","featured_media":{"alt":null,"id":37349344673960,"position":1,"preview_image":{"aspect_ratio":1.0,"height":2505,"width":2505,"src":"\/\/www.avbyfp.com\/cdn\/shop\/files\/FSII-Base---Front-Lights_Optimized.png?v=1761852952"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},], [{"variation_sku":"32384"},{"id":54325727920296,"title":"25 Beltpacks \/ 4-Pin","option1":"25 Beltpacks","option2":"4-Pin","option3":null,"sku":"32384","requires_shipping":true,"taxable":true,"featured_image":{"id":48230448169128,"product_id":9176018124968,"position":1,"created_at":"2025-10-30T12:34:47-07:00","updated_at":"2025-10-30T12:35:52-07:00","alt":null,"width":2505,"height":2505,"src":"\/\/www.avbyfp.com\/cdn\/shop\/files\/FSII-Base---Front-Lights_Optimized.png?v=1761852952","variant_ids":[54325727854760,54325727887528,54325727920296,54325727953064]},"available":true,"name":"Clear-Com Freespeak II Base Station - 25 Beltpacks \/ 4-Pin","public_title":"25 Beltpacks \/ 4-Pin","options":["25 Beltpacks","4-Pin"],"price":1225980,"weight":2722,"compare_at_price":null,"inventory_management":"shopify","barcode":"CLRCMFSIIBASEII","featured_media":{"alt":null,"id":37349344673960,"position":1,"preview_image":{"aspect_ratio":1.0,"height":2505,"width":2505,"src":"\/\/www.avbyfp.com\/cdn\/shop\/files\/FSII-Base---Front-Lights_Optimized.png?v=1761852952"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},], [{"variation_sku":"32583"},{"id":54325727953064,"title":"25 Beltpacks \/ 5-Pin","option1":"25 Beltpacks","option2":"5-Pin","option3":null,"sku":"32583","requires_shipping":true,"taxable":true,"featured_image":{"id":48230448169128,"product_id":9176018124968,"position":1,"created_at":"2025-10-30T12:34:47-07:00","updated_at":"2025-10-30T12:35:52-07:00","alt":null,"width":2505,"height":2505,"src":"\/\/www.avbyfp.com\/cdn\/shop\/files\/FSII-Base---Front-Lights_Optimized.png?v=1761852952","variant_ids":[54325727854760,54325727887528,54325727920296,54325727953064]},"available":true,"name":"Clear-Com Freespeak II Base Station - 25 Beltpacks \/ 5-Pin","public_title":"25 Beltpacks \/ 5-Pin","options":["25 Beltpacks","5-Pin"],"price":1225980,"weight":2722,"compare_at_price":null,"inventory_management":"shopify","barcode":"FSIIBASEIIX5","featured_media":{"alt":null,"id":37349344673960,"position":1,"preview_image":{"aspect_ratio":1.0,"height":2505,"width":2505,"src":"\/\/www.avbyfp.com\/cdn\/shop\/files\/FSII-Base---Front-Lights_Optimized.png?v=1761852952"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},], ]
$8,722.00
1.png__PID:7af1a3fd-a98e-4384-a357-aae772061f43
FREE SHIPPING
2.png__PID:f1a3fda9-8e83-44e3-97aa-e772061f434b

EXPERT SUPPORT

Copy of Untitled Design.png__PID:a98e8384-e357-4ae7-b206-1f434b4f7c25

HASSLE FREE RETURNS

Have a question?

Need help finding something?

Talk to a PRO

855-772-2937

CHRISTIAN.png__PID:56b62e6c-9b7a-4608-a7da-0056a14b24c8
SCHEDULE A DEMO TODAY
DESCRIPTION

The FSII-BASE-II is a base station for the wireless FreeSpeak II 1.9 GHz and 2.4 GHz active transceiver antennas and beltpacks. The FSII-BASE-II has four 2-wire connections for analog party line connection, four 4-wire audio connections, and four displays with soft keys. A dedicated stage announce (SA) output and program audio input are provided.

FEATURES
    • Wireless Intercom Base Station
    • Partyline 2-Wire Integration
    • Line-Level 4-Wire Interfacing
    • Headset User Station
    • CCM™ browser configuration & monitoring
    • Front panel configuration & monitoring
    • Plug-and-go transceivers and beltpack pairing
SPECIFICATIONS
    • Capacity: (10) E1 Transceivers (1.9, 2.4GHz); (5) or (25) Beltpacks¹ (1.9, 2.4GHz)
    • Configuration: (12) Channels; (12) Groups; (50) Roles for FreeSpeak with Point-To-Point Key Assignments
    • 4-Wire: (4) Line-Level
    • 2-Wire: (4) 400mA per pair
    • Program Audio Input: 1
    • Stage Announce Output: 1
    • GPI Input: 2
    • GPO Relay: 4
    • FreeSpeak E1: (2) RJ45/SFP switchable
    • LAN: (2) Pass Through for Management
    • Headset: 4-pin XLR-M (X4), 5-pin XLR-F (X5)
    • 2-Wire I/O: 4 XLR-3F
    • 4-Wire I/O: 4 RJ45
    • Program Audio Input: XLR-3F
    • Stage Announce Output: XLR-3M
    • GPIO: (1) DB15F (2 GPI, 4 GPO)
    • FreeSpeak II E1 TCVR/SPL Ports: (2) RJ45, (2) SFP (RJ45 or SFP selectable)
    • FSII DECT Synchronization: (2) RJ45 (Input and Output)
    • LAN: (2) RJ45
    • AC Power Connector: IEC-C14
    • DC Power Connector: KPJX-4S-S
    • Grounding Screw: Terminal
    • Front Panel: (4) OLED Displays; (2) Power Supply Status LED; (1) Headset Mic Button; (1) Front Panel Mode Button; (1) Menu Access Button; (4) Encoders for Menu & Level Control; (4) Call & Talk Buttons; (1) Stage Announce Button; (1) All Talk Button; (1) Remote Mic Kill Button; (2) Status LEDs; (1) Main Listen Level Encoder; (1) Program Audio Level Encoder
    • Rear Panel: (2) LAN RJ45 Link/Activity LEDs; (2) FSII E1 TCVR RJ45 Link/Activity LEDs; (4) 2-Wire Power / Configuration Indicator LEDs
    • Microphone Input Type: Dynamic/Electret – Selectable
    • Headset Mic Voltage: 5V
    • Input Level (nominal): -58dBu
    • Input Level (max): -10dBu
    • Frequency Response: 300Hz to 22kHz ±3dB
    • Mic Limiter Threshold: -35dBu ±3dB
    • Mic Limiter Range: ≥20dB
    • 4-Wire Input: Nominal Level 0dBu (adjustable -12dB to +12dB); Maximum Level +18dBu; Frequency Response 80Hz to 22kHz ±3dB; Impedance ≥10kΩ
    • 4-Wire Output: Nominal Level 0dBu (adjustable -12dB to +12dB); Maximum Level +18dBu; Frequency Response 80Hz to 22kHz ±3dB; Impedance 120Ω ±10%
    • 2-Wire Interface Type: Unbalanced High-Impedance bridging
    • Compatibility: Clear-Com, RTS-TW with Call and Remote Mic Kill
    • Termination: Optional per pair (A/B or C/D)
    • Nulling: User initiated Auto-Calibration
    • Null Depth: >60dB at 12kHz
    • Nominal Level: CC: -18dBu, RTS-TW: -12dBu (adjustable -3dB to +3dB)
    • Headroom: 18dB
    • Frequency Response: 80Hz to 12kHz ±3dB
    • Impedance: ≥10kΩ bridging
    • THD: <0.1% THD @1kHz
    • Power: 400mA optional per pair (A/B or C/D)
    • Voltage: 26–28V DC
    • Headset Mic: 300Hz to 22kHz
    • Headset Speaker: 50Hz to 18kHz
    • FreeSpeak II: 200Hz to 7.1kHz
    • 4-Wire: 80Hz to 22kHz
    • 2-Wire: 80Hz to 12kHz
    • Logic Inputs (GPI): 2; Opto-Isolated; Powered input, close contact to ground; Input Voltage Range 0–12V DC or AC; Input Current ≥1mA required
    • Logic Outputs (GPO/Relay): 4; SPDT / Power Relay; Normalized Open or Closed, separate pins; Switching Voltage (Max) 60V DC; Switching Current (Max) 2A
    • AC Power Input Voltage Range: 100–240V AC
    • AC Input Frequency Range: 50–60Hz
    • AC Input Power (Max): 48W
    • AC BTU (Max): 164 BTU/h
    • DC Power Input Voltage: 12V DC ±5%
    • DC Current (Max): 4A
    • DC Power (Max): 48W
    • DC BTU (Max): 164 BTU/hr
    • DC Input Power Connector: KPJX-4S-S
    • AC Input Power Connector: IEC-C14
    • External Power Adapter: PSU-EXT-002
    • Operating Temperature: 32°F to 113°F (0°C to 45°C)
    • Storage Temperature: -22°F to 158°F (-30°C to 70°C)
    • Humidity: 20–90% Non-Condensing
    • Dimensions: 19 × 1.7 × 10.2 in (482.6 × 43.2 × 259.0 mm)
    • Weight: 5.57 lbs (2.5 kg)
CONTENTS
    • (1) Clear-Com Freespeak II Base Station
