Inside each low-profile, tour-grade wood enclosure are a range of unique new features that set ETX Powered Loudspeakers apart, combining intelligent technology and innovative industrial design for spectacular results across all applications. EV-engineered high-efficiency transducers and high-powered Class-D amplifiers, Signal Synchronized Transducers (SST) waveguide design and smart FIR-Drive DSP all work together to provide peerless EV sound quality and precise coverage at the highest SPLs.
10-inch LF SMX woofer
1.25-inch HF titanium compression driver
2000 W Class-D power amplifier with integrated FIR-Drive DSP
134 dB peak SPL
Frequency Range
65 Hz -- 20 kHz Full space measurement using the music DSP preset and 150 Hz low pass.
Maximum SPL
134 peak dB Maximum SPL is measured at 1 m using broadband pink noise at maximum output.
Power Consumption
100 -- 240 V~, 50 -- 60 Hz, 1.6 -- 0.8 A Current rating is 1/8 power.
Power Rating
2000 W
Frequency Response
85 Hz -- 20 kHz Full space measurement using the music DSP preset and 150 Hz low pass.
Coverage (Nominal -6 dB) H
90 degrees
Coverage (Nominal -6 dB) V
60 degrees
LF Transducer
SMX2100 254 mm (10 in)
HF Transducer
DH3-B 1.25-in titanium compression driver
Crossover Frequency
1700 Hz
Connector Type
(2) XLR/TRS combo jack and (1) XLR link output
Enclosure Material
18-mm, 13-ply birch plywood with EVCoat
Grill
16AWG steel with powdercoat
Suspension
(8) M10 suspension points
Height
526 mm (20.71")
Width
330 mm (12.99")
Depth
365 mm (14.37")
Weight Net
20.3 kg (44.75 lbs)
Shipping Weight
22.9 kg (50.49 lbs)
(1) Electro Voice ETX-10P 10" Two-Way Powered Loudspeaker (1) US IEC Power Cord (1) Operator's Instructions
