Martin MAC Ultra Performance
Martin MAC Ultra Performance
29%, only 0 left
Martin MAC Ultra Performance
Martin MAC Ultra Performance
Product SKU
    31365

Martin MAC Ultra Performance

$13,999.99

PICK UP TODAY

recertifiedBYFP (1).png__PID:3dfb27ce-5af4-41e0-8bcb-81e313e4a56f
  • Used and Well Maintained
  • Performs Like New
  • 90 Day Guarantee

Have a question?

Need help finding something?

Talk to a PRO

855-772-2937

_EBP9032_SQ.jpeg__PID:828e756e-5126-4f82-9136-2bf92b17727c

Expertly tested refurbished and open box products

Backed by the BYFP satisfaction guarantee

Copy of Untitled Design (3).png__PID:0d4aaa6e-815d-4b5a-879b-7bd16634732b

Free Shipping

1.png__PID:3c5bc891-9c7e-4dda-94a6-30ba47708c69

Professionally Inspected

2.png__PID:5bc8919c-7ecd-4a14-a630-ba47708c69eb

Satisfaction Guaranteed

3.png__PID:c8919c7e-cdda-44a6-b0ba-47708c69eb73

Expert Support

DESCRIPTION

The MAC Ultra Performance has raised the bar for extremely bright moving lights and features benchmark output across the zoom range, a true next-generation framing system, higher definition optics, and astoundingly low noise levels.

Built to support the biggest live events, this powerful workhorse is based on our all-new 1150 W, 5800 K proprietary LED light engine, and the fixture pushes an incredible 46,500 lumens in projection. The 50,000+ hour light engine also provides high-resolution dimming, strobing, and Martin’s unique Animotion™ effect.

A 1:7 zoom range and precision focus control are provided from the refined optical system. The extensive feature package includes uniform color mixing, variable CTO, additional color and spectral correction filters, Martin’s innovative Extended Framing system, two layers of rotating gobos, a full-function animation wheel, iris, frost, and prism effects, and truly responsive and accurate pan and tilt. And these features are all packed into a compact, sturdy, and legendary Martin design.

The MAC Ultra Performance is perfect for a wide range of concert and touring productions but is equally applicable for noise-sensitive broadcast and theater stage lighting applications. Simply put, when it comes to workhorse fixtures that push the boundaries of output and performance execution, the MAC Ultra Performance stands boldly in a class all its own.

FEATURES
    • 1150 W proprietary LED light engine
    • 84 × 20 W white LEDs
    • 46,500 lumens fixture output
    • 3,000,000 cd peak luminous intensity
    • 5800 K color temperature
    • Minimum LED lifetime of over 50,000 hours
    • 160 mm front lens
    • 1:7 motorized zoom range: 8.0°–54°
    • High-resolution projection system with enhanced sharpness and contrast
    • Motorized focus with automatic tracking
    • CMY color mixing
    • Variable color temperature control from 5800–2850 K
    • 6-slot interchangeable dichroic color wheel with Spectral Enhancement Filter
    • Two rotating gobo wheels, each with 5 interchangeable gobos plus open
    • Full-function gobo animation wheel with indexing and continuous rotation
    • Extended Framing System with four individually controllable framing blades
    • ±30° blade angle across the entire beam
    • ±83° framing module rotation
    • Variable iris with pulse effects
    • Variable frost from 0–100%
    • 4-facet prism with indexing and continuous rotation
    • 0–100% continuous dimming
    • Regular, random, and pulse strobe effects
    • Four selectable dimming curves
    • Two ranges of pre-programmed FX
    • P3 video mapping of fixture color and/or intensity
    • 540° pan and 268° tilt
    • Low-noise cooling system
    • User-selectable output versus sound-level control
    • DMX, RDM, Art-Net, sACN, and P3 control
    • Built-in Ethernet switch with fail-safe bypass
    • Backlit LCD display with battery-powered operation
    • Compact, rugged design with integrated followspot handles
    • Tool-free air-inlet filter replacement
    • IP20-rated for indoor use
    • Fixture weight: 44.0 kg (97.0 lbs.)
SPECIFICATIONS
    • Light Source: 1150 W Proprietary LED Light Engine
    • LED Configuration: 84 × 20 W White LEDs
    • Minimum LED Lifetime: >50,000 Hours
    • LED Refresh Rate: 3000 Hz
    • Light Engine Luminous Output: 90,000 Lumens
    • Fixture Luminous Output: 46,500 Lumens
    • Peak Luminous Intensity: 3,000,000 cd
    • Color Temperature: 5800 K ±250 K
    • Front Lens Diameter: 160 mm
    • Zoom Range: 8.0°–54° (1:7)
    • Focus: Motorized, approximately 4.5 m to infinity
    • Color Mixing: CMY, independently variable 0–100%
    • Color Temperature Control: 5800–2850 K
    • Color Wheel: 6 Interchangeable Dichroic Filters + Open
    • Spectral Enhancement Filter: Included
    • Rotating Gobo Wheel 1: 5 Interchangeable Gobos + Open
    • Rotating Gobo Wheel 2: 5 Interchangeable Gobos + Open
    • Gobo Animation Wheel: Interchangeable, indexing, continuous rotation with variable angle, speed and direction
    • Gobo Outside Diameter: 37.5 mm
    • Maximum Image Diameter: 30 mm
    • Maximum Gobo Thickness: 1.1 mm
    • Gobo Material: Borofloat 33
    • Gobo Coating: Heavy-Matted Aluminum
    • Framing System: Martin Extended Framing System
    • Framing Module Rotation: ±83°
    • Framing Blades: 4 Individually Controllable Full-Curtain Blades
    • Blade Angle: ±30°
    • Blade Angle Range: Full Insertion Path, 0–100%
    • Dimming: 0–100% Continuous
    • Dimming Curves: 4
    • Strobe: Electronic, Regular, Random, and Pulse Effects
    • Frost: Variable 0–100%
    • Iris: Variable 0–100%, with Pulse Effects
    • Prism: 4-Facet, Indexing and Continuous Rotation
    • Animotion™: Yes
    • Pre-Programmed Effects: 2 FX Ranges, Independent or Synchronized/Combined
    • Pan Movement: 540°
    • Tilt Movement: 268°
    • Pan/Tilt Control: Coarse and Fine
    • Pan/Tilt Speed: Variable
    • Control Protocols: DMX, RDM, Art-Net, RDM over Art-Net, sACN, and P3
    • DMX Channels: Standard 48 / Extended 58
    • DMX Modes: 2
    • 16-Bit Controllable Parameters: Dimming, Color Mixing + CTC, Gobo Rotation/Indexing, Framing, Iris, Zoom, Focus, Pan, and Tilt
    • P3: Video Mapping of Fixture Color and/or Intensity
    • P3/DMX Crossfade: Variable
    • Protocol Detection: Automatic
    • Setting and Addressing: Display Menu, RDM, RDM over Art-Net, or P3
    • Fixture Identification: User-Settable ID Number
    • DMX Compliance: USITT DMX512-A
    • RDM Compliance: ANSI/ESTA E1.20
    • Art-Net Compliance: Art-Net 1, 2, 3, and 4, including RDM over Art-Net
    • sACN Compliance: ANSI E1.31-2016
    • Martin P3 Compliance: P3 System Controller Software 5.1.0 or Newer
    • DMX/RDM Transceiver: Galvanic-Isolated RS-485
    • Ethernet Transceiver: 10/100 Mbit with Fail-Safe Bypass
    • Firmware Update: USB Memory Device, DMX via Martin Companion, or Ethernet via P3 System Controller
    • Local User Interface: Backlit LCD Display with Battery-Powered Operation
    • DMX Connections: DMX-512 In/Out
    • Ethernet Connections: EtherCON In/Out for P3, Art-Net, and sACN
    • Ethernet Switch: Built-In with Fail-Safe Bypass
    • AC Input: 200–240 V AC, 50/60 Hz
    • Maximum Power Consumption: 1450 W
    • Typical Power Consumption: 1380 W
    • Typical Current at 208 V, 60 Hz: 6.8 A
    • Typical Current at 230 V, 50 Hz: 6.0 A
    • Typical Current at 240 V, 50 Hz: 5.8 A
    • Power Factor: 0.99
    • Cooling: Forced Air, Temperature-Regulated, Low Noise
    • Maximum Ambient Temperature: 40°C
    • Minimum Ambient Temperature: 5°C
    • Maximum Surface Temperature: 85°C (185°F)
    • Heat Dissipation: 4950 BTU/hr
    • Sound Pressure Level: 36.5 dB(A) at 1 m, Default Regulated Fan Mode
    • Sound Pressure Level: 35.1 dB(A) at 1 m, Constant Fan Mode Ultra Low
    • Length (Head): 660 mm (26.0 in.)
    • Length (Base): 468 mm (15.5 in.)
    • Width (Base): 312 mm (12.3 in.)
    • Width (Across Yoke): 520 mm (20.5 in.)
    • Height (Head Straight Up): 864 mm (34.1 in.)
    • Maximum Height: 876 mm (34.5 in.)
    • Minimum Center-to-Center Distance: 830 mm (32.7 in.)
    • Weight: 44.0 kg (97.0 lbs.)
    • Environmental Rating: Indoor
CONTENTS
    (1) Martin MAC Ultra Performance
    (1) PowerCON TRUE1 Power Cable
    (1) Safety Cable
    (1) User Guide
