RCF SUB9006 AS Active Subwoofer

  • $7,949.00
Zoom image

RCF SUB9006 AS Active Subwoofer

  • $7,949.00

The SUB 9006-AS is one of the most powerful 2x18” subwoofers in the field of live sound. Featuring two high-power hyper-vented 18” neodymium woofers with 4.0” inside-outside voice coils, this cabinet delivers a serious amount of low frequencies. Powered by a 7200 W digital amplifier, the SUB 9006-AS can perform in the most demanding situations. The housing of the SUB 9006-AS matches the RCF D-Line HDL50-A and HDL10-A array systems, enabling to build stacked systems in a perfect combination.

  • 7200 Watt Peak power - 3600 Watt RMS
  • 142 dB max SPL
  • 30 Hz - 400 Hz frequency response
  • 2 x 18" Woofer
  • DSP controlled Input section with selectable presets
  • RDNet remote control
  • Delay control
  • Baltic birch cabinet
Acoustical specifications Frequency Response: 30 Hz ÷ 400 Hz, Max SPL @ 1m: 142 dB
Transducers Woofer: 2 x 18'' neo, 4.0'' v.c
Input/Output section Input signal: bal/unbal, Input connectors: XLR, RDNet Ethercon, Output connectors: XLR, RDNet Ethercon, Input sensitivity: +4 dBu
Processor section Hi-Pass Frequencies: 30Hz, 40Hz, Low-Pass Frequencies: Variable from 50Hz to 400Hz, Protections: Thermal, RMS, Limiter: Fast Limiter, Controls: Gain, EQ, Preset, Phase switch, Output, Delay Settings, RDNet: Yes
Power section Total Power: 7200 W Peak, 3600 W RMS, Low frequencies: 7200 W Peak, 3600 W RMS, Cooling: Convection/Forced, Connections: Powercon IN/OUT
(1) RCF SUB9006-AS
