Professional Switching for Live Events, Web Streaming, and Studio Production

Compact and powerful, the V-80HD covers professional video production needs for in-person events, livestreaming, studio productions, and other applications. The all-in-one design is easy to carry and set up, while flexible I/O features support 3G SDI, HDMI, USB 3.0, and LAN (RTMP/SRT) connections. The V-80HD also includes multi-channel audio mixing and effects, integrated control for PTZ cameras, and remote operation with video monitoring via dedicated control apps. And with the companion Graphics Presenter software, you can easily enhance productions with impressive titles, motion graphics, and more.

Professional eight-channel switcher with a compact footprint and comprehensive features
Supports a variety of applications, including in-person events, conferences, web streaming, houses of worship, and studio production setups
Four 3G SDI inputs with frame rate converters
Four 1080p HDMI inputs, including two 4K inputs with HD downscalers and through outputs
Seven total outputs include SDI, HDMI, USB-C streaming, and LAN (RTMP/SRT)
Powerful live production automation with sequencing, macros, and scene memories

Two 3G SDI and three HDMI outputs plus 10 assignable buses
28-channel digital audio mixer and three output buses with effects and processing
Five-layer video effects engine, including two PinP windows with key composition and DSK
Easily create stunning titles and motion graphics with the companion Graphics Presenter software for Windows
32-slot still store function supports screen capture or uploaded BMP, JPEG, and PNG images via alpha channel in the internal non-volatile memory

Multiple Video Inputs

The V-80HD features versatile input connectivity with HDMI for common A/V devices and SDI for long cable runs and high-end cameras. Eight total channels are available, enabling seamless switching for up to four HDMI and four SDI input sources. Two 4K HDMI inputs are equipped with downscalers and the ability to send parallel connections to gaming consoles at eSports events. Additionally, an SRT input can be assigned to a cross-point button together with an SDI and HDMI input.

v-80hd_img_02.png__PID:1ac33c85-86ed-4f39-8a5d-4122f305a5dd

v-80hd_img_03.jpg__PID:c33c8586-eddf-498a-9d41-22f305a5ddfc

Versatile Video Outputs and Flexible Routing

With its multiple assignable outputs—including two SDI and three HDMI video outputs, a USB-C streaming output, and LAN (RTMP/SRT)—the V-80HD puts a high-end video matrix at your command. Each output can be assigned to 10 buses, allowing you to feed program displays, auxiliary monitors, multi-view producer displays, and online audiences all at once.

Powerful Video Effects Engine

The V-80HD is filled with tools to elevate presentations with impressive video effects and graphics. The onboard effects engine features five composition layers that include a split-screen effect, two PinP windows with key composition, and one DSK with fill/key composite support. It’s simple to create common layouts, such as a business presentation with an individual speaker, image slides, and a title on a background. PinP and DSK layers can be managed individually on the Program, Sub-Program, and two Aux outputs, providing flexibility for any production need.

Rapid Workflow with Scenes and Macros

Storing and recalling custom looks can be accomplished with just a few button presses on the V-80HD. The 32 scene memories and powerful effects engine work together to provide seamless scene changes, including synchronizing the transition of all composition layers at the program output. The 100 macros go even deeper, allowing you to build and fire off complex action lists that include switching, DSK on/off, audio mixing adjustments, PTZ camera movements, and much more.
Our free remote control software for macOS, Windows, and iPad further enhances this workflow, providing a large graphical interface for setting up and previewing actions before you take them live

v-80hd_img_09.jpg__PID:68a02dad-01cf-4a99-a503-20f0e5d370af

Secure AV Transmission with SRT

The V-80HD supports SRT (Secure Reliable Transport), an open-source standard for AVoIP that provides secure encrypted audio and video transmission over IP networks. It also offers future-proof connectivity within installed system configurations. SRT allows you to seamlessly extend your V-80HD production capabilities via LAN or an internet connection. Access camera images from remote locations and switch them along with local HDMI and SDI sources. And send a dedicated SRT video output to an external destination, such as another building at the production location.

Plug-and-Play Streaming

The V-80HD uses the same connection technology as webcams, providing a plug-and-play streaming experience. Simply connect the USB-C output to a computer or smartphone and start streaming with Zoom, Microsoft Teams, or any platform that can use a webcam as its source. LAN connectivity is also supported, allowing you to stream directly to YouTube, Facebook Live, Twitch, or any RTMP platform without a computer.

v-80hd_img_08.jpg__PID:0c4b3ff5-d6dc-4c36-bfe9-d8c583d78018

v-80hd_img_06.jpg__PID:e87ca91f-1b17-4a50-a39d-5480313e0fdb

Professional Graphics Made Easy

The Graphics Presenter software for Windows allows you to create stunning titles and graphics without the need for expensive third-party graphic presentation solutions. Setup with the V-80HD is quick and straightforward, requiring only a single HDMI connection to send fill and key signals from the computer to the switcher.

Graphics Presenter offers an intuitive workflow with a wide selection of ready-to-edit templates, including animated title text, sports scores, motion graphics, and more. The software and templates are available free of charge, and additional content is periodically provided for download on Roland Cloud.

v-80hd_img_10.jpg__PID:c962b4c3-1c87-4650-b582-e3e1a2f94e05

SDXC Card Recording

With the V-80HD’s onboard recorder, you can easily capture an event to an SDXC card and provide your client with an H.264 MP4 video file* for their editing and distribution needs. Stereo WAV audio can also be recorded independently for podcasts and other audio-driven media. It’s even possible to capture still images to internal memory from any video output bus and save them to the card for later use.

v-80hd_img_11.jpg__PID:ba39c4e3-fd8b-4f36-bb79-2a8ad2ab309c

PTZ Camera Support

Robotic PTZ (pan-tilt-zoom) cameras greatly expand production capabilities, offering extended coverage with studio-grade broadcast quality. And thanks to their small size, they can be placed in discreet locations where larger cameras aren’t practical.

The V-80HD includes built-in control support for select Canon, JVC, Panasonic, Sony, PTZOptics, Avonic, and VISCA-compatible PTZ LAN cameras. Mix and match different brands and operate up to eight PTZ cameras simultaneously. The V-80HD Remote iPad App is an ideal companion for PTZ operation, providing remote camera controls and video monitoring from the tablet.

Sequencing Magic

Storing and recalling custom looks can be accomplished with just a few button presses on the V-80HD. The 32 scene memories and powerful effects engine work together to provide seamless scene changes, including synchronizing the transition of all composition layers at the program output. The 100 macros go even deeper, allowing you to build and fire off complex action lists that include switching, DSK on/off, audio mixing adjustments, PTZ camera movements, and much more.
Our free remote control software for macOS, Windows, and iPad further enhances this workflow, providing a large graphical interface for setting up and previewing actions before you take them live

Features

• Professional eight-channel switcher with a compact footprint and comprehensive features • Supports a variety of applications, including in-person events, conferences, web streaming, houses of worship, and studio production setups • Four 3G SDI inputs with frame rate converters • Four 1080p HDMI inputs, including two 4K inputs with HD downscalers and through outputs • Seven total outputs include SDI, HDMI, USB-C streaming, and LAN (RTMP/SRT) • Two 3G SDI and three HDMI outputs plus 10 assignable buses • 28-channel digital audio mixer and three output buses with effects and processing • Five-layer video effects engine, including two PinP windows with key composition and DSK • Easily create stunning titles and motion graphics with the companion Graphics Presenter software for Windows • 32-slot still store function supports screen capture or uploaded BMP, JPEG, and PNG images via alpha channel in the internal non-volatile memory • Powerful live production automation with sequencing, macros, and scene memories • Integrated PTZ camera control with simultaneous support for multiple brands and mixed protocols • Eight assignable pads for controlling up to 64 discreet functions • Extensive device control with Bluetooth, USB, RS-232, and LAN • Wireless and wired camera tally support • Remote control software available for iPad, macOS, and Windows

Specifications

VIDEO: Video Processing: 4:2:2 (Y/Pb/Pr), 8-bit Number of Video Channels: 8 channels Video Input Formats: HDMI IN 1--4: 480/59.94i, 480/59.94p, 720/59.94p, 1080/59.94i, 1080/59.94p, 1080/60p, 1080/29.97p, 1080/30p *1; 576/50i, 576/50p, 720/50p, 1080/50i, 1080/50p, 1080/25p *2; 1080/23.98p, 1080/24p; 2160/59.94p, 2160/60p, 2160/29.97p, 2160/30p *1, *3; 2160/50p, 2160/25p *2, *3; 2160/23.98p, 2160/24p *3; VGA (640 x 480/60 Hz), SVGA (800 x 600/60 Hz), XGA (1024 x 768/60 Hz); WXGA (1280 x 800/60 Hz), SXGA (1280 x 1024/60 Hz); FWXGA (1366 x 768/60 Hz), SXGA+ (1400 x 1050/60 Hz); UXGA (1600 x 1200/60 Hz), WUXGA (1920 x 1200/60 Hz); * The refresh rate is the maximum value of each resolution.; * Conforms to CEA-861-E,VESA DMT Version 1.0 Revision 11.; * 1920 x 1200/60 Hz: Reduced blanking; * The input interlaced video signal is converted to progressive video signal by internal processing.; * The input refresh rates of SVGA (800 x 600)--SXGA+ (1400 x 1050) are 75 Hz when the unit's frame rate setting is 50 Hz.; * HDMI IN 1 support Roland FILL+KEY signal; *1 Frame Rate = 59.94 Hz, 60 Hz, *2 Frame Rate = 50 Hz, *3 Only for HDMI IN 3, 4; SDI IN 1--4: 720/59.94p *1, *3; 720/50p *1, *4; 1080/59.94i, 1080/59.94p, 1080/60p, 1080/29.97p, 1080/30p *2, *3; 1080/50i, 1080/50p, 1080/25p *2, *4; 1080/23.98p, 1080/24p *2; * The input interlaced video signal is converted to progressive video signal by internal processing.; *1 System Format = 720p; *2 System Format = 1080i or 1080p; *3 Frame Rate = 29.97 Hz, 30 Hz, 59.94 Hz, 60 Hz, *4 Frame Rate = 25 Hz, 50 Hz Video Output Formats: HDMI OUT 1--3, SDI OUT 1--2: 720/59.94p *1, *4; 720/60p *1, *5; 720/50p *1, *8; 1080/59.94i *2, *4; 1080/60i *2, *5; 1080/50i *2, *8; 1080/59.94p *3, *4; 1080/60p *3, *5; 1080/29.97p *3, *6; 1080/30p *3, *7; 1080/50p *3, *8; 1080/25p *3, *9; 1080/23.98p *3, *10; 1080/24p *3, *11; *1 System Format = 720p; *2 System Format = 1080i; *3 System Format = 1080p; *4 Frame Rate = 59.94 Hz; *5 Frame Rate = 60 Hz; *6 Frame Rate = 29.97 Hz; *7 Frame Rate = 30 Hz; *8 Frame Rate = 50 Hz; *9 Frame Rate = 25 Hz; *10 Frame Rate = 23.98 Hz; *11 Frame Rate = 24 Hz; USB STREAM: 1080/59.94p, 720/59.94p, 640 x 480/59.94p *1; 1080/60p, 720/60p, 640 x 480/60p *2; 1080/29.97p, 720/29.97p, 640 x 480/29.97p *3; 1080/30p, 720/30p, 640 x 480/30p *4; 1080/50p, 720/50p, 640 x 480/50p *5; 1080/25p, 720/25p､640 x 480/25p *6; 1080/23.98p, 720/23.98p､640 x 480/23.98p *7; 1080/24p, 720/24p､640 x 480/24p *8; * Uncompressed format (YUY2) and Compressed format (Motion JPEG) supported.; *1 Frame Rate(USB Out) = 59.94 Hz, *2 Frame Rate(USB Out) = 60 Hz, *3 Frame Rate(USB Out) = 29.97 Hz, *4 Frame Rate(USB Out) = 30 Hz, *5 Frame Rate(USB Out) = 50 Hz, *6 Frame Rate(USB Out) = 25 Hz, *7 Frame Rate(USB Out) = 23.98 Hz, *8 Frame Rate(USB Out) = 24 Hz; DIRECT STREAM: 720/59.94p *1, *3; 720/60p *1, *4; 720/29.97p *1, *5; 720/30p *1, *6; 720/50p *1, *7; 720/25p *1, *8; 1080/59.94p *2, *3; 1080/60p *2, *4; 1080/29.97p *2, *5; 1080/30p *2, *6; 1080/50p *2, *7; 1080/25p *2, *8; 1080/23.98p *2, *9; 1080/24p *2, *10; *1 System Format = 720p, *2 System Format = 1080p, *3 Frame Rate (Stream&Record) = 59.94 Hz, *4 Frame Rate (Stream&Record) = 60 Hz, *5 Frame Rate (Stream&Record) = 29.97 Hz, *6 Frame Rate (Stream&Record) = 30 Hz, *7 Frame Rate (Stream&Record) = 50 Hz, *8 Frame Rate (Stream&Record) = 25 Hz, *9 Frame Rate (Stream&Record) = 23.98 Hz, *10 Frame Rate (Stream&Record) = 24 Hz Stream and Record formats: Audio Video: Protocols: RTMP, RTMPS, SRT (Caller, Listener); Container: FLV (RTMP, RTMPS), MPEG2-TS (SRT); Recording File Format: MP4; Codec: H.264, target bitrate up to 20,000 kbps; AAC-LC, 16 bits, 48 kHz, stereo, target bitrate up to 384 kbps; * When the format of either Stream & Record or Video Player/SRT In exceeds 1080/30p, the Stream & Record and Video Player/SRT In functions cannot be used simultaneously.; * When the sum of the bitrate for Stream & Record and Video Player/SRT In exceeds 20,000 kbps, the Stream & Record and Video Player/SRT In functions cannot be used simultaneously.; Audio: Recording File Format: WAV; Codec: Linear PCM, 16 bits, 48 kHz, stereo Video Player: Video Player: File Format: MP4; Codec: H.264, Average bit rate of 20,000 kbps or less, up to 1080/60p; AAC-LC, 16 bits, 48 kHz, stereo; SRT In: Protocol: SRT (Caller, Listener); Container: MPEG2-TS; Codec: H.264, Average bit rate of 20,000 kbps or less, up to 1080/60p; AAC-LC, 16 bits, 48 kHz, stereo; * When the format of either Stream & Record or Video Player/SRT In exceeds 1080/30p, the Stream & Record and Video Player/SRT In functions cannot be used simultaneously.; * When the sum of the bitrate for Stream & Record and Video Player/SRT In exceeds 20,000 kbps, the Stream & Record and Video Player/SRT In functions cannot be used simultaneously. Still Image: Bitmap File (.bmp) Up to 1920 x 1080 pixels, 24-bit color, uncompressed.; PNG File (.png) Up to 1920 x 1080 pixels, 24-bit color; JPEG File (.jpg, .jpeg) Up to 1920 x 1080 pixels, 24-bit color; * It can be stored up to 32 files in the internal memory.; * It can be exported to the SD Card and USB flash drive.; * PNG alpha channel supported. Video Effects: Transition: Cut, Mix (Dissolve/FAM/NAM), WIPE (8 types), SPLIT (2 types); Composition: PinP x 2 (Square, Circle, Diamond), Keyer x 2 (Luminance Key, Chroma Key), DSK (Luminance Key, Chroma Key, Alpha Key, External Key), Roland FILL+KEY Mode; Other: Multi-View (3 types), Flip horizontal, Flip vertical, Still Image capture, Still Image playback, Output fade (Audio, Video: White or Black), Test pattern output, Stream Delay AUDIO: Audio Processing: Sample rate: 24 bits, 48 kHz Number of Audio Channels: 28 channels Audio Formats: USB STREAM (input/output): Linear PCM, 16 bits, 48 kHz, 2 ch; Bluetooth (input): Linear PCM, 16 bits, 48 kHz, 2 ch; HDMI IN: Linear PCM, 24 bits, 48 kHz, 2 ch; HDMI OUT: Linear PCM, 24 bits, 48 kHz, 8 ch; SDI IN: Linear PCM, 24 bits, 48 kHz, 2 ch (Conforms to SMPTE 299M); SDI OUT: Linear PCM, 24 bits, 48 kHz, 8 ch (Conforms to SMPTE 299M) Audio Player: File format: WAV (Linear PCM, 16 bits, 48 kHz/44.1 kHz, stereo); * It can be stored up to 64 tracks in the internal memory. Audio Effects: Channel Effects: High pass filter, Echo canceller, Anti-feedback, Noise gate, De-esser, Compressor, 4-Band equalizer, Voice changer, Delay, Auto mixing; Master Effects: Reverb, 4-Band equalizer, Compressor/Limiter, Loudness Auto Gain Control, Adaptive Noise Reduction, Low Frequency Cut, 15-Band GEQ, Delay; Other: Output fade, Test tone output COMMON SECTION: Recording Media: SDHC/SDXC card (commercially available); USB flash drive (commercially available); * SDXC card is required for video recording. Other Functions: Scene Memory (32 types); Macro Control (100 types); Sequencer Control (1,000 steps); Panel lock function; EDID Emulator; Auto Switching; Auto Input Detect; Smart Tally; Remote Camera Control (Up to 8 units); External Rec Control; Menu language (English, Japanese, Simplified Chinese) CONNECTORS: Video Input Connectors: HDMI IN 1--4: HDMI type A x 4; * HDCP Supported; * Multi-format Supported; SDI IN 1--4: BNC type x 4; * Conforms to SMPTE 424M (SMPTE 425M-AB), 292M Video Output Connectors: HDMI OUT 1--3: HDMI type A x 3; * HDCP Supported; HDMI IN 3--4 THRU: HDMI type A x 2; * HDCP Supported; SDI OUT 1--3: BNC type x 2; * Conforms to SMPTE 424M (SMPTE 425M-AB), 292M; •USB STREAM: USB Type-C (R) Audio Input Connectors: Analog: AUDIO IN 1--2: Combo type (XLR, 1/4-inch TRS phone), phantom power DC 48 V (unloaded maximum), 10 mA (maximum load); AUDIO IN 3/L, 4/R: RCA phono type; Digital: USB STREAM: USB Type-C (R); Bluetooth; HDMI IN 1--4: HDMI type A x 4; SDI IN 1--4: BNC type x 4 Audio Output Connectors: Analog: AUDIO OUT 1--2: XLR type; PHONES: Stereo 1/4-inch phone type; Digital: USB STREAM: USB Type-C (R); Bluetooth; HDMI OUT 1--3: HDMI type A x 3; HDMI IN 3--4 THRU: HDMI type A x 2; SDI OUT 1--2: BNC type x 2 Other Connectors: USB HOST: USB A type (for USB flash drive, for remote control from USB numeric keypad); USB STREAM: USB Type-C (R) (for remote control from PC and iPad, Graphics Presenter); Bluetooth: for remote control from iPad; CTL/EXP 1, 2:1/4-inch TRS phone type (for remote control from foot switch and expression pedal); TALLY/GPIO: DB-25 type (Female)(Tally/GPO: 16, GPI: 8); RS-232: DB-9 type (Male) (for Remote Control); DIRECT STREAM: RJ45, 1000BASE-T (for Live Streaming, SRT In/Out and Remote Control) AUDIO INPUT/OUTPUT CHARACTERISTICS: Input Level: AUDIO IN 1, 2: -64--+4 dBu (Maximum: +24 dBu); AUDIO IN 3/L, 4/R: -10 dBu (Maximum: +10 dBu) Input Impedance: AUDIO IN 1, 2: 8.4 k ohms; AUDIO IN 3/L, 4/R: 10 k ohms Output Level: AUDIO OUT 1, 2: +4 dBu (Maximum: +24 dBu); PHONES: 92 mW + 92 mW (32 ohms) Output Impedance: AUDIO OUT 1, 2: 600 ohms; PHONES: 33 ohms OTHERS: Bluetooth: Ver 5.0; Profile Support: A2DP (Audio), GATT (MIDI over Bluetooth Low Energy); Codec: SBC (Support to the content protection of the SCMS-T method) Display: 4.3 inches TFT Color LCD: 480 x 272 dots Power Supply: AC adaptor Current Draw: 2.1 A Power Consumption: 51 W Operation Temperature: +0 to +40 degrees Celsius; +32 to +104 degrees Fahrenheit Dimensions: 396 (W) x 254 (D) x 103 (H) mm; 15-5/8 (W) x 10 (D) x 4-1/16 (H) inches Weight (excluding AC adaptor): 3.5 kg; 7 lbs 12 oz Accessories: Startup Guide; Leaflet "USING THE UNIT SAFELY"; AC adaptor; Power cord Options (sold separately): Footswitch: BOSS FS-5U, FS-6, FS-7; Expression Pedal: EV-5, EV-30, BOSS FV-500L, FV-500H

Contents

(1) V-80HD Direct Streaming Video Switcher (1) Startup Guide (1) Pamphlet “USING THE UNIT SAFELY” (1) AC adaptor (1) Power cord
