Four-channel digital full-rack (19") receiver with internal PSU and Dante® for use with Evolution Wireless Digital handheld, bodypack, and table stand transmitters. Extended 88 MHz switching bandwidth, intermodulation-free operation [intermodulation-free equidistant channel spacing] for up to 293 channels with secure AES 256 encryption and four modular network ports.
FEATURES
-
• Four-channel digital full rack (19") receiver with internal PSU and with Dante® in rugged metal housing
• Up to 88 MHz switching bandwidth
• Auto-switching PSU with IEC Connection
• Four network ports for flexible network configurations - each port can be assigend as: Control, Control + Dante® Prim, Control + Dante® Sec, Dante® Prim, Dante® Sec
• Integrated antenna splitter with antenna power and loop through to daisy chain up to 16 channels (4 x EW-DX EM 4)
• Low latency of 1.9 ms wireless transmission thanks to proprietary Sennheiser Performance Audio Codec (SePAC)
• 140 dB input dynamic range - no need to set gain on your wireless transmitters at all, thanks to proprietary Sennheiser Performance Audio Codec (SePAC)
• Equidistant channel spacing to easily allocate intermodulation-free channels: Standard Mode with 600 kHz spacing for up to 146 channels; Link Density (LD) Mode with 300 kHz spacing for up to 293 channels
• Works seamlessly with SoundBase software, unifying your workflow into a single, simple platform
• Network enabled for expanded remote control with Sennheiser Control Cockpit, Wireless System Manager), and 3rd party media control systems via plug-in
• Ethernet connectivity (IPv4 and IPv6)
• AES-256 & Dante Media Encryption offers the strongest protection against signal hacking
• AutoScan-feature quickly scans your environment and deploys frequencies with equidistant channel spacing - even without RF knowledge
• Link Quality Indicator (LQI) showing the quality of the links seperate to the RF levels
• Remote control via Smart Assist App over Bluetooth® Low Energy (BLE) at distances up to 25 meters
• Clear and easy focused user interface with OLED display, jog wheel navigation and control buttons
• Selective headphone output with volume control on front panel
• Extended menu settings such as custom frequency list, selectable sync parameter and walk test
• Worldwide usage (specific frequencies subject to local RF regulations)
SPECIFICATIONS
-
• Input Voltage: 90 to 265 V AC, 47 to 63 Hz
• Power Consumption: Max. 37 W
• Transmission Power: BLE: max. 10 mW EIRP
• Audio Output Power: 18 dBu max.
• Headphone Output: 2x 70 mW @ 32 Ω
• Ethernet: Dante® digital audio output, RJ-45; 48 kHz, 96 kHz, 24 bit; Daisy chain output 2x BNC (50 Ω); 0 dB +/- 0.5 dB amplification relative to antenna inputs; Cascaded receiver (RF), max. 4 EW-DX EM 4 Dante
• Dimensions (W × H × D): 483 × 44 × 373 mm (19.0 × 1.73 × 14.7 in)
• Weight: Approx. 4560 g (without antennas and power supply unit)
CONTENTS
-
(1) Sennheiser EW-DX EM 4 DANTE Rack Receiver
(2) Rod Antennas
(2) BNC Antenna Cables (50 Ω) for Daisy-Chaining
(3) Main Cables (EU, UK, US Plug)
(1) Quick Guide
(1) Safety Guide
(1) Manufacturer Declaration Sheet
