Shure SLXD14/98H-G58
19%, only 0 left
Shure SLXD14/98H-G58
Product SKU
    30042

Shure SLXD14/98H-G58

$699.99

PICK UP TODAY

recertified+.png__PID:7672a0bd-1cf7-4ba8-9841-5171b10f1ebf
  • Like New Condition
  • Original Packaging
  • Full Factory Warranty

Have a question?

Need help finding something?

Talk to a PRO

855-772-2937

_EBP9032_SQ.jpeg__PID:828e756e-5126-4f82-9136-2bf92b17727c

Expertly tested refurbished and open box products

Backed by the BYFP satisfaction guarantee

Copy of Untitled Design (3).png__PID:0d4aaa6e-815d-4b5a-879b-7bd16634732b

Free Shipping

1.png__PID:3c5bc891-9c7e-4dda-94a6-30ba47708c69

Professionally Inspected

2.png__PID:5bc8919c-7ecd-4a14-a630-ba47708c69eb

Satisfaction Guaranteed

3.png__PID:c8919c7e-cdda-44a6-b0ba-47708c69eb73

Expert Support

DESCRIPTION

The SLX14D/98H Wireless System delivers transparent, 24-bit digital audio and rock-solid RF performance for a wide range of applications, from day-long conferences to nighttime performances. Operate up to 32 compatible systems per 44 MHz band, with easy setup and optional rechargeability accessories for wireless excellence, wherever required.

FEATURES
    Shure SLXD4 Single-Channel Receiver:
    • Transparent 24-bit digital audio
    • Extended 20 Hz to 20 kHz frequency range (microphone dependent)
    • 118 dB dynamic range
    • Digital predictive switching diversity
    • 44 MHz tuning bandwidth (region dependent)
    • 32 available channels per frequency band (region dependent)
    • Up to 10 compatible systems per 6MHz TV band; 12 systems per 8 MHz band
    • Easy pairing of transmitters and receivers over scan and IR sync
    • Up to 8 hours from 2 AA batteries or optional Shure SB903 rechargeable battery
    • Interchangeable microphone capsules
    • Rugged metal construction

    Shure SLXD1 Bodypack Transmitter:
    • Transparent 24-bit digital audio
    • Extended 20 Hz to 20 kHz frequency range (microphone dependent)
    • 120 dB dynamic range
    • Digital predictive switching diversity
    • Operating range of 100 m (300 ft.)
    • 44 MHz tuning bandwidth (region dependent)
    • 32 available channels per frequency band (region dependent)

    Shure WB98H/C Wireless Instrument Microphone:
    • transformerless preamplifier circuitry, which improves linearity across the full frequency range
    • High gain-before-feedback and excellent rejection of unwanted noise
    • High maximum SPL handles the demands of brass, woodwind, and percussion instruments
    • Tailored frequency response for studio-quality performance
    • Wide dynamic range for use in high-SPL environments
    • Compact design reduces stage clutter
    • Detachable cable for easy storage
    • Interchangeable microphone cartridges with different polar patterns are available
    • Optional A98D drum mount allows precise microphone positioning while holding it securely in place
    • Legendary Shure quality, ruggedness, and reliability
SPECIFICATIONS
    Shure SLXD4 Single-Channel Receiver:
    • RF Carrier Frequency Range: 470–937.5 MHz
    • Working Range: 100 m (328 ft)
    • RF Tuning Step Size: JB Band: 125 kHz; All Other Bands: 25 kHz
    • Image Rejection: >70 dB
    • RF Sensitivity: -97 dBm at 10-5 BER
    • Audio Latency: 3.2 ms
    • Audio Frequency Response: 20 Hz–20 kHz (+1, -2 dB)
    • Audio Dynamic Range A-weighted, typical: 120 dB
    • Total Harmonic Distortion: <0.02%
    • System Audio Polarity: XLR: Positive pressure on microphone diaphragm produces positive voltage on pin 2 with respect to pin 3 of XLR output. TRS: Positive pressure on microphone diaphragm produces positive voltage on the tip of the 6.35 mm (1/4-inch) with respect to the ring of the 6.35 mm output.
    • Mic Offset Range: 0 to 21 dB (in 3 dB steps)
    • RF Input Spurious Rejection: >75 dB
    • Connector Type: BNC
    • RF Input Impedance: 50 Ω
    • Audio Output Gain Adjustment Range: –18 to +42 dB in 1 dB steps
    • Configuration: 1/4" (6.35 mm): Balanced (Tip=audio +, Ring=audio –, Sleeve=ground) XLR: Balanced (1=ground, 2=audio +, 3=audio –)
    • Audio Output Impedance: 1/4" (6.35 mm): 1.3 kΩ (670 Ω Unbalanced) XLR (line): 400 Ω (200 Ω Unbalanced) XLR (mic): 150 Ω
    • Full Scale Output: 1/4" (6.35 mm): +15 dBV differentially (+9 dBV single) XLR (LINE setting): +15 dBV XLR (MIC setting): –15 dBV
    • Mic/Line Switch: 30 dB pad
    • Phantom Power Protection: 1/4" (6.35 mm): Yes XLR: Yes
    • Network Interface: Single Port Ethernet 10/100 Mbps
    • Network Addressing Capability: DHCP or Manual IP address
    • Maximum Cable Length: 100 m (328 ft)

    Shure SLXD1 Bodypack Transmitter:
    • Battery Type: Rechargeable Li-Ion or 1.5 V AA batteries
    • Housing: PC/ABS
    • Audio Input Connector: 4-Pin male mini connector (TA4M)
    • Audio Input Configuration: Unbalanced
    • Audio Input Impedance: 1 MΩ
    • Maximum Input Level: 8.2 dBV (2.57 Vrms, 7.27 Vpp)
    • Preamplifier Equivalent Input Noise (EIN): –118 dBV
    • RF Output Antenna Type: 1/4 Wave
    • Occupied Bandwidth: <200 kHz
    • Modulation Type: Shure Proprietary Digital
    • Power: 1 mW/10 mW

    Shure WB98H/C Wireless Instrument Microphone:
    • Type: Electret Condenser
    • Frequency Response: 20 to 20,000 Hz
    • Polar Pattern: Cardioid
    • Output Impedance: 150 Ω
    • Sensitivity (at 1 kHz, open circuit voltage): -56 dBV/Pa (1.6 mV) 1 Pascal=94 dB SPL
    • Maximum SPL (1 kHz at 1% THD, 1kΩ load): 155 dB SPL (typical)
    • Equivalent Output Noise (A-weighted): 31 dB SPL (typical)
    • Signal-to-Noise Ratio (Referenced at 94 dB SPL at 1 kHz): 63 dB
    • Dynamic Range (at 1 kHz, 1 kΩ load): 124 dB 132 dB
    • Preamplifier Output Clipping Level (1% THD): 3 dBV (1.4 V)
    • Polarity: Positive pressure on diaphragm produces positive voltage on pin 2 with respect to pin 3
    • Power Requirements: 11 to 52 Vdc phantom
CONTENTS
    (1) Shure SLXD4 Single-Channel Receiver
    (1) Shure SLXD1 Bodypack Transmitter
    (1) Shure WB98H/C Wireless Instrument Microphone
    (1) Rackmount Accessories
    (2) AA Batteries
