Shure SLXD4D Dual Wireless Receiver H55 Band
Shure SLXD4D Dual Wireless Receiver H55 Band
29%, only 0 left
Shure SLXD4D Dual Wireless Receiver H55 Band
Shure SLXD4D Dual Wireless Receiver H55 Band
Product SKU
    35459

Shure SLXD4D Dual Wireless Receiver H55 Band

$649.99

SEE PRODUCT IN STORE

PICK UP TODAY

recertifiedBYFP (1).png__PID:3dfb27ce-5af4-41e0-8bcb-81e313e4a56f
  • Used and Well Maintained
  • Performs Like New
  • 90 Day Guarantee

Have a question?

Need help finding something?

Talk to a PRO

855-772-2937

_EBP9032_SQ.jpeg__PID:828e756e-5126-4f82-9136-2bf92b17727c

Expertly tested refurbished and open box products

Backed by the BYFP satisfaction guarantee

Copy of Untitled Design (3).png__PID:0d4aaa6e-815d-4b5a-879b-7bd16634732b

Free Shipping

1.png__PID:3c5bc891-9c7e-4dda-94a6-30ba47708c69

Professionally Inspected

2.png__PID:5bc8919c-7ecd-4a14-a630-ba47708c69eb

Satisfaction Guaranteed

3.png__PID:c8919c7e-cdda-44a6-b0ba-47708c69eb73

Expert Support

DESCRIPTION

The Shure SLX-D Dual-Channel Digital Wireless Receiver is a high-performance system designed for reliable, crystal-clear audio in demanding environments. It features 24-bit digital audio quality with wide dynamic range and low latency, making it ideal for professional sound reinforcement applications such as live performances, conferences, and broadcasting. The SLX-D system provides rock-solid RF stability, ensuring minimal interference and dropouts, with up to 120 dB of dynamic range and a robust transmission over a wide frequency spectrum. The receiver's intuitive interface includes a high-resolution LCD for easy monitoring, and it supports multiple receivers with easy synchronization via IR scanning. Additionally, the receiver can operate up to 32 channels per frequency band, allowing for scalable setups in complex environments.

FEATURES
    • Transparent 24-bit digital audio
    • Extended 20 Hz to 20 kHz frequency range (microphone dependent)
    • 120 dB dynamic range
    • Digital predictive switching diversity
    • 44 MHz tuning bandwidth (region dependent)
    • 32 available channels per frequency band (region dependent)
    • Up to 10 compatible systems per 6 MHz TV band; up to 12 systems per 8 MHz band
    • Easy pairing of transmitters and receivers over scan and IR sync
    • Rugged metal construction
SPECIFICATIONS
    • RF Carrier Frequency Range: 514–558 MHz (H55)
    • Working Range: 100 m (328 ft)
    • RF Tuning Step Size: 25 kHz
    • Image Rejection: >70 dB, typical
    • RF Sensitivity: –97 dBm at 10⁻⁵ BER
    • Audio Latency: 3.2 ms
    • High-Pass / Low-Cut Filter: 150 Hz at –12 dB/oct; factory default is Off
    • Audio Frequency Response: 20 Hz–20 kHz (+1, –2 dB)
    • Audio Dynamic Range: 118 dB at 1% THD, A-weighted, typical
    • Total Harmonic Distortion: <0.02%
    • System Audio Polarity: Positive pressure on the microphone diaphragm produces positive voltage on pin 2 relative to pin 3 of the XLR output and on the tip relative to the ring of the 6.35 mm output.
    • Mic Offset Range: 0–21 dB, in 3 dB steps
    • RF Input Spurious Rejection: >75 dB, typical
    • RF Input Connector Type: BNC
    • RF Input Impedance: 50 Ω
    • RF Input Phantom Power Protection: Yes
    • Audio Output Gain Adjustment Range: –18 to +42 dB, in 1 dB steps
    • Audio Output Configuration: 1/4" (6.35 mm): Balanced (Tip = audio +, Ring = audio –, Sleeve = ground), XLR: Balanced (1 = ground, 2 = audio +, 3 = audio –)
    • Audio Output Impedance: 1/4": 1.3 kΩ (670 Ω unbalanced), XLR Line: 400 Ω (200 Ω unbalanced), XLR Mic: 150 Ω
    • Full Scale Output: 1/4": +15 dBV differentially (+9 dBV single), XLR Line: +15 dBV, XLR Mic: –15 dBV
    • Audio Output Mic/Line Switch: 30 dB pad
    • Network Interface: Single-port Ethernet, 10/100 Mbps
    • Network Addressing Capability: DHCP or Manual IP Address
    • Maximum Cable Length: 100 m (328 ft)
    • Dimensions (H × W × D): 42 × 393 × 152 mm (1.65 × 15.47 × 5.98 in)
    • Weight: 1,451 g (3.2 lb), without antennas
    • Housing: Galvanized steel
    • Power Requirements: 15 V DC @ 600 mA, supplied by external power supply (tip positive)
    • Compatible Systems: Up to 10 compatible systems per 6 MHz TV band; up to 12 systems per 8 MHz band
CONTENTS
    (1) Shure SLXD4D Dual Wireless Receiver H55 Band
    (1) Power Cable
    (1) User's Manual
