EVE E-50Z is an LED ellipsoidal that shines a hard-edged, warm white spot and features D-Fi™ USB compatibility for wireless Master/Slave or DMX control. Manual zoom gives you the flexibility to project from any distance and its framing shutters let you easily alter and control the projected beam. EVE E-50Z includes holders for glass and steel gobos as well as a gel frame. You can operate EVE E-50Z in standalone mode eliminating the need for DMX control and you can save time running extension cords by power linking multiple units.
LED Ellipsoidal shines a hard-edged, warm white spot in any direction
Easily highlight areas by altering the projected beam with framing shutters
Flexibility to project from any distance using the manual zoom
D-Fi USB compatibility for wireless Master/Slave or DMX control
PowerCON®-compatible power input/output connections for power linking
DMX Channels
1 or 3
DMX Connectors
3-pin XLR
Light Source
1 LED (warm white) 50 W, (1.3 A), 50,000 hours life expectancy
Strobe Rate
0 to 29 Hz
Illuminance
(20°) 7,910 lux @ 2 m; (39°) 2,710 lux @ 2 m
Power Linking
16 units @ 120 V; 26 units @ 230 V
Input Voltage
100 to 240 VAC, 50/60 Hz (auto-ranging)
Power and Current
59 W, 0.5 A @ 120 V, 60 Hz; 63 W, 0.3 A @ 230 V, 50 Hz
Gobo Size
D (53.3 mm outside, 43 mm image, 2mm max thickness)
Zoom Angle
(Manual) 20° to 39
Weight
9.2 lb (4.2 kg)
Dimensions
18.9 x 6.2 x 15 in (480 x 157 x 381 mm)
Approvals
CE
Color Temperature
3500 K
Gel Frame Size
5.5 in
Optional Controllers
D-Fi USB
(1) Chauvet DJ EVE E-50Z Light Fixture (1) Power Cord (1) Gel Frame (1) Gobo Holder for Glass Gobos (1) Operator's Instructions (1) Hanging Bracket with Mounting Hardware (1) Gobo Holder for Steel Gobos
